Connecting to an External Amplifier
Wiring
REAR R REAR R
FRONT R FRONT R
FRONT L FRONT L
REAR L REAR L GREEN(+) GREEN(+)
GREEN/BLACK(-) GREEN/BLACK(-)
WHITE(+) WHITE(+)
WHITE/BLACK(-) WHITE/BLACK(-)
GREY(+) GREY(+)
GREY/BLACK(-) GREY/BLACK(-)
PURPLE(+) PURPLE(+)
PURPLE/BLACK(-) PURPLE/BLACK(-)
CENTER CENTER BLACK (-) BLACK (-)
BLACK/WHITE(+) BLACK/WHITE(+)
External Power Amplifier
If your head unit does not have a built-in center amp, the JCCSPK must be
connected through a properly rated external amplifier (as shown below).
