Fuses
187
Spare ATO fuses are located in the tool tray
situated under the floor in the luggage
compartment.
ENGINE COMPARTMENT FUSE BOX
Fuse No Rating
(amps)
Fuse
Color Circuit
F1 - - -
F2 15A Blue Ignition coils
F3 5A Tan CDCS ECU, EPB, EMS, ECM
F4 30A Green Power wash pump.
F5 - - -
F6 - - -
F7 40A Orange RH front glass heater.
F8 - - -
F9 - - -
F10 - - -
F11 - - -
F12 - - -
F13 - - -
F14 - - -
F15 - - -
F16 - - -
F17 15A Blue TCM, ETS.
F18 20A Yellow EMS main, EMS secondary control.
F19 30A Green Starter.
F20 40A Orange DSC pump.
F21 25A Clear ABS slip valves.
F22 - - -
F23 - - -
F24 15A Blue Intercooler water pump.
F25 15A Blue Horns.
F26 40A Orange Wiper motor.
F27 - - -
F28 15A Blue ECM, VVT diode.
