Jabra BT 5020 Bluetooth headset
US
ES
PT
FR
Specifications:
• Talk time up to 10 hours/standby time up to 300 hours
• Rechargeable battery with charging option from AC power supply, PC via
USB cable or car charger (not included)
• Weight 16 grams
• Battery indicator
• Operating range up to 33 feet (approx. 10 meters)
• Headset and hands-free Bluetooth profiles
• Bluetooth specification (see glossary) version 2.0
4. Getting started
The Jabra BT5020 is easy to operate. The answer/end button on the headset
performs the different functions depending on how long you press it.
Instruction: Duration of press
Tap Press briefly
Double Tab 2 quickly repeated Taps
Press Approx: 1 second
Press and hold Approx: More than 3 seconds
1) Charge your headset
Make sure that your Jabra BT5020 headset is fully charged before you start
using it. Use the AC adapter to charge from a power socket, or charge directly
from your PC with the USB cable provided. Connect your headset as shown
in fig. x. When the LED is solid red, your headset is charging. When the LED is
green, it is fully charged.
Please note: The lifetime of the battery will be significantly reduced if your
device is left uncharged for a long period. We therefore recommend that you
recharge your device at least once a month.
2) Turning your headset on and off
• Press the on/off/pairing button to turn on your headset. The LED will
show a green flash when the headset is on.
• Press and hold the on/off/pairing button to turn off your headset. The
LED will turn red when headset is off.
3) Pair it with your phone
Before you use your Jabra BT5020, you need to pair it with your mobile phone.
The first time you turn on the Jabra BT 5020 it will automatically go into pairing
mode. If you would like to pair again at another time, follow the instructions
below.
A. Put the headset in pairing mode
• Make sure the headset is off .
• Press and hold the answer/end button until a solid blue light comes on.
B. Set your Bluetooth phone to ‘discover’ the Jabra BT020
Follow your phone’s instruction guide. This usually involves going to a ‘setup,’
‘connect’ or ‘Bluetooth’ menu on your phone and selecting the option to
‘discover’ or ‘add’ a Bluetooth device.* (See example from a typical mobile
phone in fig. 3)
C. Your phone will find the Jabra BT020
Your phone then asks if you want to pair with it. Accept by pressing ‘Yes’
or ‘OK’ on the phone and confirm with the passkey or PIN = 0000 (4 zeros).
Your phone will confirm when pairing is complete. In case of unsuccessful
pairing, repeat steps 1 to 3.
5. Wear it how you like it
The Jabra BT5020 is ready to wear on your right ear. If you prefer the left,
gently rotate the ear piece to fit left ear. See fig. 4.
For optimal performance, wear the Jabra BT 5020 and your mobile phone
on the same side of your body or within line of sight. In general, you will get
better performance when there are no obstructions between your headset and
your mobile phone.
