Connecting the AM Antenna
Rear Panel of the Unit
CAUTION:
• To avoid noise, keep antennas away from the System, the connecting cord and the AC power
cord.
SUB WOOFER
CD DIGITAL OUT
ANTENNA
AM EXT FM(75 )
COAXIAL
AM LOOP
OUT IN
MD / AUX
SPEAKERS IMPEDANCE 4 16
R
AC IN
L
Attach the AM loop to its base by snapping the
tabs on the loop into the slot in the base.
AM loop antenna (Supplied)
ANTENNA
AM EXT FM(75 )
COAXIAL
AM LOOP
Turn the loop until you have the best reception.
