65
Replacing the Light Bulb
1 Face cover plate
2 Lamp socket
3 Holder
4 Lamp
5 Pins
* Turn the power switch off.
* Wait until the lamp has cooled down before touching
it.
• Removing the light bulb
[1] Open face cover plate.
[2] Remove the black rubber lamp socket from the lamp
holder and pull out the light bulb.
• Attaching the light bulb
[3] To insert the lamp in the lamp socket, match the pins
on the lamp with the lamp socket holes.
[4] Attach the lamp socket on the holder and close face
cover plate.
[1]
[2] [3] [4]
1
2
3
4
5
