Jacuzzi Signa D578 - Manual

signa ® 5 whirlpool bath and soaking bath (with 3 tile fl ange)
the signa ® whirlpool bath takes its name from the medieval central italian walled city, lastra a signa.
Like the walled city for which it is named,
Signa
® 5 was specially developed and
designed for walled surround spaces.
whirlpool bath features:
• Contoured backrest.
• 4 Fully adjustable TheraPro™ jets
• 2 AccuPro™ foot jets.
• Exclusive Tru-Level™ self-leveling base system
• Slip-resistant bottom.
• Patented Fixed Air Flow System
• Drain included on whirlpool baths
signa ® 5 with 3 tile fl ange
soaking bath
model number: D578 (w/3-tile fl ange)
exterior dimensions:
60" long x 42" wide x 22" high
interior dimensions:
41" long x 25" wide
signa ® 5 with 3 tile fl ange
whirlpool bath
model number: D560 – RH pump,
D569 – LH pump
exterior dimensions:
60" long x 42" wide x 22" high
interior dimensions:
41" long x 25" wide
# of Jets/type of Jets:
4 TheraPro™ Jets
2 AccuPro™ Back Jets
operating gallons:
42 gallons
