Jøtul C 450 Kennebec
Non-Catalytic
Clean Burn
Cast Iron & Steel
27 1/2” x 23” x 14”-17”
450 lbs.
6”
40” x 18”
up to 20”
(21”=firebox width)
55,000 BTU/hr
up to 1,600 sq. ft.
71%
4.4 grams/hr
up to 8 hours
Jøtul C 550 Rockland
Non-Catalytic
Clean Burn
Cast Iron & Steel
33” x 23 3/4” x 19
550 lbs.
6”
37” x 16”/20”Can
up to 24”
65,000 BTU/hr
up to 1,800 sq.ft.
71%
4.0 grams/hr
up to 10 hours
Model
Combustion
Technology
Construction
Minimum Fireplace Dimensions
Weight
Flue Size
Minimum Hearth Dimensions
Log Length
Maximum Heat Output1
Heating Capacity2
Overall Efficiency3
Emissions
Burn Time
Jøtul C 350 Winterport
Non-Catalytic
Clean Burn
Cast Iron & Steel
32” x 19 1/2” x 16”
272 lbs.
6”
34 1/2” x 16”
up to 20”
40,000 BTU/hr
up to 1,300 sq. ft.
71%
4.0 grams/hr
up to 7 hours
All dimensions measured from the fireplace cavity
centerline or the hearth surface
Minimum Dimensions
Jøtul C 350 Jøtul C 450
Jøtul C 550
A: Hearth Width from
centerline
17 1/4”
20”
18 1/2”
B: Hearth Depth
16”
18”
16”/20” CAN***
C: To 1” Side Trim from
centerline
19 1/2”
20 3/4”
21 3/4”
D: To Side Wall from
centerline
54 1/2”
44 1/4”
54”
E: To 1” Top Trim
39”*
n/a
n/a
F: To 3 1/2” Mantel
48”*
49 1/2”
51 3/4”/57 3/4” CAN**
To 11 1/2 Mantel
54”*
55 1/2”
57 3/4”/63 1/2” CAN**
G: Front Opening Width
32”
27 1/2
33”
H: Lintel Height
19 1/2”*
23”
23 3/4”
I: Rear Wall Height
16 3/4”
21 1/2”
22”
J: Rear Wall Width
22 3/4”
25 1/2”
24”
K: Fireplace Depth
16”
14”-17”
19”
* Add 2” w/ Jøtul C 350 Riser
** Mantel clearance may be reduced by 15 1/2” in both US and
Canada with use of optional Mantel Heat Shield
*** 18” in Canada with 2 1/2” raised hearth extension in code approved
masonry fireplace
1 Maximum Heat Output is based on kg of dry wood burned per hour
2 Heat Capacity and Maximum Burn Time will vary depending on design of home,
climate, wood type and operation
3 Overall Efficiency is based on a burn rate of .75kg wood per hour
* Depth is overall depth with ashlip and smoke outlet included
