Connecting the system
Refer to the illustration below to connect speakers, subwoofer and antennas. To install the S DVR 52 into your current TV sys-
tem, refer to the three configuration examples. Choose from one of them or make your own combination.
Be sure to connect + to + and – to – from the S DVR 52 to the speakers and subwoofer. If the cables are reversed, the sound
will be distorted and lack bass.
Front right
Centre
Front left
Subwoofer
Surround left
Surround right
