MSR7007
5
BASIC OPERATION
Power On/Off
Press the POWER button (1) to turn the unit on or off. The unit will resume at the last mode
selected (Tuner, Aux, etc.).
Volume Control
To increase the volume, press the VOLUME + button (2a). To decrease the volume, press the
VOLUME - button (2b). While adjusting the volume, the LCD displays a bar graph and
numerical representation of the level. The maximum volume setting is 40.
Mute
Press the MUTE button (16) on the control panel to mute the audio output. Press MUTE again
to restore the audio output to the previous level.
Mode
Press the MODE button (4) on the control panel to select a different mode of operation, as
indicated on the display panel. Available modes include Tuner (AM/FM), SAT Radio, CD, iPod
and AUX In (optional Auxiliary Input).
NOTE: CD, iPod, or SIRIUS mode will be skipped if the module is not installed.
NOTE: SIRIUS Radio mode will be skipped when the Region menu option is set to
“EURO”.
Reset
Use a ball point pen or similar object to press the RESET button (23). The RESET button
should be activated for the following reasons:
• initial installation of the unit when all wiring is completed
• function buttons do not operate
• error symbol on the display
Audio Menu
Press the AUDIO/MENU button (3) on the control panel to access the audio menu. You can
navigate through the audio menu items by pressing the AUDIO/MENU button repeatedly. Once
the desired menu item appears on the display, adjust that option by pressing the VOLUME
buttons (2) within 5 seconds. The unit will automatically exit the audio menu after five seconds
of inactivity. The following menu items can be adjusted.
Bass Level
Use the VOLUME buttons (2) to adjust the Bass level range from “-6” to “+6”.
Treble Level
Use the VOLUME buttons to adjust the Treble level range from “-6” to “+6”.
Balance
Use the VOLUME buttons to adjust the Balance between the left and right speakers from “12L”
(full left) to “12R” (full right).
Fader
Use the VOLUME buttons to adjust the Fader between the rear and front speakers from “12R”
(full rear) to “12F” (full front).
Front Panel
Important Notes
•
Always operate the unit with the front panel door closed.
• When closing the front panel door, do not apply pressure to the OPEN slide button.
• Do not force front panel door operation when opening or closing.
• Do not touch the door open detection switch (24).
Front Panel Door Alarm
To prevent damage to the unit by entry of water or debris through the CD opening, the front
panel door should only be opened for a short period of time during CD loading or ejecting. If the
front panel door is left open for longer than 30 seconds, the current playback audio will mute
and a beep tone will sound. Close the door to resume normal playback.
22 20 23
RESET
24
3
16
5
11
6
12
7
13
8 14 9 15 10 4
2a
1
18
21 19 17
2b
MODE
MUTE PTY
DISP
SCROLL
INFO
VIEW BEHIND CD DOOR
