JAI CV-A33CL - Manual (Page 24)

CV-A33CL
- 23 -
9.2. Specification table
Specifications CV-A33CL
Scanning system Progressive scan
Pixel clock 40.000 MHz (25 nsec)
Line frequency 59.44 kHz (673 pixels clock/line) (16.825 µsec)
Frame rate 118.4 frames/sec. (502 lines/frame) (8.44615 msec)
CCD sensor 1/2” progressive scan monochrome
CMOS image sensor: Micron MT9V403C12 STM
Sensing area 6.61 (h) x 4.97 (v) mm
Cell size 9.9 (h) x 9.9(v) µm
Effective pixels 667 (h) x 502 (v)
Pixels in video output Full
“ Window 659 (h) x 493 (v) 118.4 fps
>2 (h) x >3 (v)
Max window scan frame rate <4953 fps. 659 (h) x 3 (v)
Auto trigger sensing rate <5403 fps. 659 (h) x 3 (v)
Sensitivity on sensor 13 Lux (Min. gain, shutter 1/120, 100% video)
1.2 Lux (Max. gain, shutter 1/120, 50% video)
S/N ratio >45 dB
Digital video output 10/8 bits in Camera Link
Gain
Gain range Remote
0 to +15 dB
Synchronization Int. X-tal. Ext. random trigger
Inputs Camera Link
TTL Ext. trigger
Ext. trigger TTL 4 V ±2 V. (TTL or 75 Ω terminated)
Outputs Camera Link
TTL Pixel clock, LVAL, FVAL, DVAL, EEN
EEN (4 V from 75 Ω)
Control interface TXD and RXD via RS 232C
TDX and RDX via Camera Link
Trigger modes Continuous, Edge pre-select, Pulse width control, Auto trigger
Accumulation LVAL a-synchronous
Shutter Global (simultaneous exposure for all pixels)
Read out modes Full or Partial as user selectable window of interest
Shutter speed (fixed) 1/120 through 1/20,000 second
Programmable exposure 1 LVAL to 492 LVAL (16.8 µsec. to 8.3 msec.)
Pulse width control >1 LVAL to <237 FVAL (>16.8 µsec. to <2.0 sec.)
Partial readout window of interest X origin, Y origin, X width, Y height
With 1 pixel increment
Functions controlled by
RS 232C Shutter, Trigger, Scanning, Readout,
Trigger input, Black level and Gain
Operating temperature -5°C to +45°C
Humidity 20 – 80% non-condensing
Storage temp/humidity -25°C to +60°C/20% to 90%
Vibration 10G (20Hz to 200Hz in all directions)
Shock 70G
EMC CE (EN50081-1 and EN50082-1), FCC part 15, UL94
Power 12V DC ± 10%. 2.5 W
Lens mount C-mount (Flange back 17.526 mm ±0.05mm)
Image centre ±0.1mm from C-mount centre
Dimensions 35 x 44 x 58 mm (HxWxD)
Weight 120g
