EON 500 Series
EON510
Powered speaker 10” + 1” 220W + 60W amp + mixer € 825
EON515
Powered speaker 15” + 1” 350W + 100W amp + mixer € 1.105
EON518S
Powered 18”subwoofer 500W with build in crossover € 1.245
EON 510 EON 515 EON 518 S
SYSTEM TYPE Self-powered 10”, two -way, bass-reflex design Self-powered 15”, two -way, bass-reflex design Self-powered 18”, two -way, bass-
reflex design
FREQ RANGE (-10 dB)1 58 Hz - 18,5 kHz (EQ in ‘Flat’ position) 39 Hz - 20 kHz (EQ in ‘Flat’ position) 36 Hz - 130 kHz
COVERAGE PATTERN 100°H x 60° V nominal 100°H x 60° V nominal -
CROSSOVER FREQUENCY 1.8 KHZ 2,2 kHz 120 Hz (HPF selectable on outputs)
SYSTEM POWER RATING 280W Continuous, 560 W peak 450W Continuous, 900 W peak 500W continuous, 1000W peak
LF Driver 1 x JBL 261F, 10” Differential drive ® integrated 1 x JBL 265F, 15” Differential drive ® integrated 1 x JBL 268G, 18” Differentialdrive ®
woofer with dual 1,5” voice coils woofer with dual voice coils integrated woofer with dual 2” voice
coils
HF Driver 1 JBL 2414H-1 1” neodymium compression driver 1 JBL 2414H-1 1” neodymium compression driver
MAXIMUM SPL 121 dB 129 dB 129 dB
SYSTEM EQ Boost: LF +3 dB Shelving filter @ 150 HZ Boost: LF +3 dB Shelving filter @ 200 HZ -
HF +2,5dB Shelving filter @ 4 kHz HF +2,5dB Shelving filter @ 4 kHz -
Cut: Preset high pass @ 120 Hz Cut: High pass Filter @ 120 Hz -
INPUT 3 CONNECTOR Balanced XLR/ 1/4” TRS Combo jack Balanced XLR/ 1/4” Combo jack with -
XLR loop through
INPUT 1 & 2 CONNECTOR 1/4” TRS Jack 1/4” TRS Jack -
OUTPUT (Loop/Mix Switch) Balanced male XLR, +20 dB (peak) o/p Balanced male XLR, +20 dB (peak) o/p -
Level in MIX position Level in MIX position -
SUSPENSION/MOUNTING 36 mm pole socket with stabilizing screw, 36 mm pole socket with stabilizing screw, 36 mm pole socket on top
3 x M10 suspension points, 1 x M10 suspension 3 x M10 suspension points, 1 x M10 suspension
points, 1 x M10 pull back point points, 1 x M10 pull back point
AC INPUT 120-240V, 50/60Hz 120-240V, 50/60Hz 120-240V, 50/60Hz
DIMENSIONS (H x W x D) 490 x 313 x 262 mm 685 x 438x 366 mm 617x 569 x 652 mm
NET WEIGHT (each) 7,7 kg 14,8kg 29,5 kg
EON 500 Series
EON 500 Series
Portable systems
Versatile - Everywhere you need great sound!
Extreme Light weiht set.
Do-it-all system for gigging musicians, touring bands
and mobile DJ’s.
EON 500 Series:
Floor monitor
Floor standing
Suspended
Pole mount
