English – 35
TECHNICAL DATA
Bar and chain combinations
The following recommended combinations of bar and saw chain are type approved for your chain saw. The saw chain Jonsered
H36 is designed to minimize kickback (classified saw chain of low kickback type according to ANSI B175.1).
Saw chain filing and file gauges
EC-declaration of conformity
(Applies to Europe only)
Jonsered, SE-561 82 Huskvarna, Sweden, tel +46-36-146500, declares under sole responsibility that the chain saw Jonsered
CS 2139T from 2005’s serial numbers and onwards (the year is clearly stated in plain text on the type plate with subsequent serial
number), is in conformity with the requirements of the COUNCIL’S DIRECTIVES:
- of June 22, 1998 ”relating to machinery” 98/37/EC, annex IIA.
- of May 3, 1989 ”relating to electromagnetic compatibility” 89/336/EEC, and applicable supplements.
- of May 8, 2000 ”relating to the noise emissions in the environment” 2000/14/EC.
For information relating to noise emissions, see the chapter Technical data. The following standards have been applied: EN ISO
12100-2:2003, CISPR 12:1997, EN ISO 11681-2.
Notified body: 0404, SMP Svensk Maskinprovning AB, Fyrisborgsgatan 3, SE-754 50 Uppsala, Sweden, has carried out EC type
examination in accordance with the machinery directive’s (98/37/EC) article 8, point 2c. The certificates for EC type examination
in accordance with annex VI, have the numbers: 404/05/1061
In addition, SMP, Svensk Maskinprovning AB, Fyrisborgsgatan 3, SE-754 50 Uppsala, Sweden, has certified conformity with annex
V of the Council’s Directive of May 8, 2000 ”relating to the noise emissions in the environment” 2000/14/EC. The certificates have
the numbers: 01/161/056.
The supplied chain saw conforms to the example that underwent EC type examination.
Huskvarna 4 may 2005
Bo Andréasson, Managing Director
Bar Chain
Length, inch Pitch, inch Gauge, mm Max. nose radius Type Length, drive links (no.)
12 3/8 1,3 7 T
Jonsered H36
45
14 3/8 1,3 7 T 50
