ICEU060 Series Service Parts Cabinet
Item Part Item Part
No. Description Number No. Description Number
1 Top Panel 1011337-01 11 Lower Back Panel 1011337-13
2 Insulation 1011137-02 12 Back Panel 1011337-14
2a Cover 1011137-03 13 Screw 1011337-15
3 Brace 1011337-04 14 Screw 1011337-16
4 Upper Door Frame 1011337-05 15 Bin Thermostat Brkt. 1011337-17
5 Door 1011337-06 16 Unit Frame 1011337-18
6 Door Bushing (4) 1011337-07 17 Storage Bin Assy. 1011337-19
7 Curtain 1011337-08 18 Pump Bracket 1011337-20
8 Front Panel 1011337-09 Curtain Bracket 1011337-21
9 Leg 1011337-10 19 Scoop 1011337-22
Leg Spacer 1011337-11 20 Front Plate 1011337-23
10 Leg Leveler 1011337-12 21 Right Side Panel 1011337-71
22 Left Side Panel 1011337-72
