InFocus Play Big IN82 User Manual
Page 3
2
Table of Contents
Introduction 3
Positioning the projector
5
Choosing the aspect ratio
6
Connecting a video device
7
Video connectors
7
Digital connections
7
HDMI 1.3 connection
8
DVI connection
8
Component (RCA) connection
8
S-video connection
8
Composite (RCA) video connection
8
Computer connections
8
RS-232 connections
8
Displaying an image
9
Adjusting the image
9
Shutting down the projector
11
Troubleshooting your setup
11
Using the remote control
17
Optimizing video images
18
Customizing the projector
18
Using the menus
19
Picture menu
20
Settings menu
24
Maintenance 27
Replacing the projection lamp
27
Appendix 29
Remote control discrete codes
29
Projector dimensions for ceiling mount installations 29
RS-232 terminal Product Interface specifications
31
Important Operating Considerations for Safety
•
Place the projector in a horizontal position no greater than 15 degrees off
axis.
•
Locate the projector in a well-ventilated area without any obstructions to
intake or exhaust vents. Do not place the projector on a tablecloth or other
soft covering that may block the vents.
•
Locate the projector at least 4' (1.2 m) away from any heating or cooling
vents.
•
Use only InFocus-approved ceiling mounts.
•
Use only the power cord provided. A surge-protected power strip is recom-
mended.
•
Refer to this guide for proper startup and shutdown procedures.
•
Hg – Lamp contains mercury. Manage in accordance with local dis-
posal laws. See www.lamprecycle.org.
•
In the unlikely event of a lamp rupture, particles may exit through the projec-
tor side vents. When the projector is turned on, keep people, food, and
drinks out of the "keep out" area under and around the projector, as indicated
by the "X" areas below.
Follow these instructions to help ensure image quality and lamp life over the life of
the projector. Failure to follow these instructions may affect the warranty. For
complete details of the warranty, see the Warranty booklet.
5’
/ 1
.5 m
8’ / 2.4 m
2’
/ 0
.6
m
3’ / 1 m
