Cornelius ENDURO-150 User Manual

Page 16

background image

14

620904401

CAPACITOR

24V

LINE

FILTER

EMI FILTER

220–240V

POWER SWITCH

AGITATOR MOTOR

GATE

SOLENOID

OPTIONAL

BEVERAGE TRANSFORMER

MOTOR HEATER

OPTIONAL LIGHT

OPTIONAL
STARTER

OPTIONAL
BALLAST

TIMER

L1

L2

OPTIONAL LOW ICE LEVEL LIGHT

OPTIONAL

BEVERAGE

VALVES

N.O.

L

RECTIFIER

N.C.

C

VEND SWITCH

G

N

BEVERAGE PANEL

OPTIONAL

BEVERAGE

VALVES

T’STAT

FIGURE 10. WIRING SCHEMATIC (220 V)
