Operating the ThinkPad 570 Battery
Charger
To charge the battery pack, do as follows:
1 Have the battery pack for the ThinkPad 570 computer in hand.
2 Connect the AC Adapter to the power jack of the battery
charger 1 . Connect the power cable to the AC Adapter 2
and then to an electrical outlet 3 .
Make sure the power-on indicator ( ) on the battery charger is
on.
1
2
3
3 Insert the battery pack into the slot of the battery charger.
Make sure the charging indicator ( ) starts blinking slowly,
which means that charging has started.
4 When the charging indicator stops blinking and stays on,
remove the battery pack from the battery charger.
The battery pack is fully charged and ready to use.
Note: Full charging takes 2—3 hours.
Note: Use the AC Adapter supplied with your ThinkPad 570 computer.
1-2
