Parts list – Ironman Fitness Viper User Manual
Page 24
Ref # Part #
DESCRIPTION
Qty
Ref # Part #
Description
Qty
A1
323-00586 FRONT MAIN FRAME
1
A30
319-00386 COVER, FOR CRANK
2
A2
323-00592 REAR MAIN FRAME
1
A31
313-00426 POWER CORD FRONT
1
A3
319-00382 ALUMINUM TRACKING
1
A32
313-00427 POWER CORD REAR
1
A4
306-00975 FRONT LEFT CHAIN COVER
1
A32-1 302-01561 NUT A32-1
1
A5
306-00976 FRONT RIGHT CHAIN COVER
1
A33
306-00959 COVER, DECORATION FOR CORD STAND
1
A6
319-00391 REAR LEFT CHAIN COVER
1
A34
302-01563 SCREW, HEXAGON 4X12MM
1
A7
319-00392 REAR RIGHT CHAIN COVER
1
A35
305-00233 SENSOR PIPE HOUSING
1
A8
306-00965 COVER, FOR SLIDING TRACKING
1
A36
302-01537 SCREW, FIXING A36
1
A9
319-00394 SLIDING TRACK
1
A37
302-01541 WASHER, FLAT A37
2
A9-1
306-00974 WHEEL
4
A38
302-01565 NUT, NYLON A38
4
A9-2
302-01536 SCREW, FIX FOR WHEEL-A9-2
4
A39
302-01535 SCREW, CROSS FOR MOTOR A39
4
A9-3
302-01560 METAL BUSHING, A9-3
2
A40
302-01543 SCREW, HEXAGON A40
1
A9-4
310-00247 FIXING PIN
1
A41
302-01548 SCREW, HEXAGON A41
1
A9-5
302-01571 SPRING A9-5
1
A42
302-01534 SCREW, CROSS-A42
2
A9-6
302-01564 NUT M16 A9-6
1
A43
302-01556 SCREW, HEXAGON A43
6
A9-7
323-00598 PULL BAR
1
A44
302-01576 SCREW, TAPPING A44
34
A9-8
306-00966 END CAP
1
A45
302-01546 SCREW, HEXAGON A45
1
A9-9
306-00980 LEFT DECORATION FOR REAR TUBE
1
A46
302-01549 SCREW, HEXAGON A46
1
A9-10 306-00981 RIGHT DECORTATION FOR REAR TUBE
1
A47
302-01645 SCREW, HEXAGON M4X20MM
4
A10
323-00580 BACKREST TUBE
1
A48
302-01646 SCREW, HEXAGON M4X12MM
6
A10-1 319-00412 AXLE FOR BACKREST TUBE
1
A49
302-01647 SCREW, HEXAGON 8X5/8
4
A10-2 302-01542 WASHER FLAT A10-2
2
A50
302-01648 SCREW, HEXAGON M8X70MM
1
A10-3 306-00967 END CAP FOR BACKREST TUBE
1
A51
302-01649 NUT, A51
8
A11
323-00581 SEAT ADJUSTMENT HANDLE
1
A52
302-01650 WASHER, FLAT 17X22X.3
2
A11-1 306-00979 PLASTIC WRAP
2
A53
302-01651 WASHER, FLAT M6X16X1.2
1
A11-2 305-00232 CONNECTING HOUSING
1
B1
323-00597 FRONT STABILIZER
1
A11-4 319-00384 AXLE FOR BRAKING
1
B2
306-00968 END CAP FOR FRONT TUBE
1
A11-5 302-01527 BUSHING-L A11-5
1
B3
306-00973 TRANSPORATION WHEEL
2
A11-6 302-01528 BUSHING-R A11-6
1
C1
323-00593 REAR STABILIZER
1
A11-7 328-00081 BRAKE PAD, SEAT
1
C2
306-00970 END CAP FOR REAR TUBE LEFT
1
A11-8 319-00385 BRAKING STOPPER
1
C3
306-00969 END CAP FOR REAR TUBE RIGHT
1
A11-9 302-01574 SCREW, STOPPING A11-9
2
D
306-00977 MAIN SUPPORTING TUBE
1
A11-10 302-01532 C CLIP- A11-10
1
E
323-00587 FRONT SMALL HANDLE BAR
1
A12
310-00245 GAS CYLINDER, FOR TRACKING BASE ADJUST
1
E1-1 323-00589 COVER, FOR LEFT HANDLE BAR LEFT
1
A12-1 302-01579 METAL BUSHING
2
E1-2 323-00590 LEFT HANDLE BAR COVER RIGHT
1
A13
310-00246 GAS CYLINDER, FOR BACKREST ADJUST
1
E2-1 305-00235 RIGHT HANDLE BAR COVER(L)
1
A13-1 302-01578 PLASTIC BUSHING
2
E2-2 305-00234 RIGHT HANDLE BAR COVER ®
1
A13-2 310-00248 GAS CYLINDER BAR
1
E2-3 302-01652 SCREW, HEXAGON M3X15MM
2
A13-3 306-00978 PLASTIC WRAP
1
E3-1 323-00584 CONTROLLER FOR LEFT HANDLE BAR FRONT
1
A13-4 302-01544 SCREW, HEXAGON A13-4
1
E3-2 323-00583 CONTROLLER FOR LEFT HANDLE BAR BACK
1
A13-5 302-01562 NUT, A13-5
2
E3-3 307-00730 PLASTIC CIRCUIT BOARD LEFT
1
A14
311-00104 FLYWHEEL
1
E4-1 323-00585 CONTROLLER FOR RIGHT HANDLE BAR FRONT
1
A14-1 302-01655 WASHER, FLAT 10X13X.3
3
E4-2 323-00582 CONTROL FOR RIGHT HANDLE BAR REAR
1
A14-2 302-01656 WASHER, FLAT 30X34X.8
1
E4-3 307-00731 PLASTIC CIRCUIT BOARD RIGHT
1
A14-3 302-01531 C CLIP-A14-3
2
E5
313-00424 HAND PULSE SENSOR WIRE
2
A14-4 302-01539 NUT, FLANGE A14-4
2
E6
313-00430 SENSOR WIRE LEFT
1
A14-5 302-01638 NUT, FLANGE 3/8X3T
1
E7
313-00431 SENSOR WIRE RIGHT
1
A14-6 302-01639 NUT, FLANGE 3/8X5T
1
E8-1 313-00420 HAND PULSE
8
A15
319-00390 PRESSING PIPE
1
E8-2 328-00082 PAD FOR HAND PULSE
8
A15-1 302-01567 PRESSING SPRING A15-1
1
E8-3 302-01568 SCREW E8-3
8
A15-2 331-00118 WHEEL
1
E9
302-01569 SCREW E9
2
A15-3 319-00389 WASHER, FLAT A15-3
2
F
307-00729 MONITOR
1
A15-4 302-01540 WASHER, FLAT A15-4
3
F1
302-01533 SCREW, CROSS-F1
2
A15-5 302-01547 SCREW, HEXAGON A15-5
3
G
328-00084 SEAT, VIPER
1
A15-7 302-01529 C CLIP C12
1
H
323-00579 BACKREST
1
A15-8 302-01641 WASHER M6X19X1.5
1
I
306-00962 COVER, FOR MAIN SUPPORTING TUBE
1
A16
302-01559 HOUSING-MAGNET A16
1
J-( L ) 323-00591 LEFT SIDE HANDLE BAR
1
A16-1 302-01570 SPRING A16-1
1
J-( R ) 323-00596 HANDLE BAR, FOR RIGHT SIDE
1
A16-2 302-01580 TENSION CABLE, VIPER
1
J1
313-00423 HAND PULSE SENSOR WIRE
2
A16-3 302-01642 SCREW, HEXAGON M6X60MM
1
J2-1
306-00961 COVER, HANDLE BAR UPPER LEFT
1
A16-4 302-01643 NUT, FLANGE M6
1
J2-2
306-00960 COVER, HANDLE BAR DOWN LEFT
1
A16-5 302-01644 NUT, FLANGE M6
1
J3-1
306-00964 COVER, HANDLE BAR UPPER RIGHT
1
A17
302-01526 BELT PULLEY A17
1
J3-2
306-00963 COVER, HANDLE BAR DOWN RIGHT
1
A17-1 319-00383 AXLE FOR BELT PULLEY
1
J4
306-00971 END CAP FOR SIDE HANDLE BAR
2
A17-2 302-01530 C CLIP- A17-2
2
K1
302-01632 BOTTLE HOLDER, VIPER
1
A17-3 302-01558 MAGNET A17-3
1
K2
302-01633 BOTTLE HOLDER, VIPER
1
A17-4 302-01550 SCREW, HEXAGON A17-4
4
K3
302-01634 SCREW M8*9.5, VIPER
2
A17-5 304-00030 BELT 6PJ 46
1
M
313-00419 ADAPTOR
1
A17-6 302-01566 NUT, NYLON A17-6
4
N1
302-01545 SCREW, HEXAGON N1
16
A18
331-00119 BEARING
2
N2
302-01572 WASHER, SPRING N2
6
A19
306-01023 END CAP 40X80MM
1
N3
302-01577 WASHER N3
6
A20
306-01024 END CAP 40X100MM
1
N4
302-01551 SCREW, HEXAGON N4
2
A21
307-00732 MOTOR, VIPER
1
N5
302-01553 SCREW, HEXAGON N5
2
A22
313-00429 SENSOR WIRE
1
N6
302-01552 SCREW, HEXAGON N6
4
A23
313-00421 HAND PULSE SENSOR MIDDLE
1
N7
302-01555 SCREW, HEXAGON N7
6
A24
313-00422 HAND PULSE SENSOR REAR
1
N8
302-01653 SCREW, HEXAGON M8X20MM
2
A25
313-00425 HAND PULSE SENSOR FRONT
1
N9
302-01654 WASHER, FLAT M6X8MM
2
A26
313-00428 SENSOR WIRE
1
N10
302-01575 SCREW, HEXAGON M6X8MM
1
A27
319-00387 CRANK LEFT
1
#
302-01582 BOLT PACK, VIPER
1
A28
319-00388 CRANK RIGHT
1
#
306-01025 LEVELER, BOTTOM OF UNIT
1
A29
302-01538 SCREW, HEXAGON 8X25MM
2
VIPER RECUMBENT BIKE PARTS LIST REV B
24
Parts List
