Wiring
Caution
Make sure that you connect the color-coded leads
according to the diagram. Incorrect connections
may cause the car deck to malfunction or damage
the vehicle’s electrical system.
Be sure to connect the (-) speaker leads to the (-)
speaker terminal. Never connect the left and right
channel speaker cables each other or to the
vehicle body.
Make sure all the connections are completely
correct before turning on your car deck.
Antenna
Front L RCA
Front R RCA
Rear L RCA
Rear R RCA
Ma
gnifie
r
Ma
gnifie
r
