S.=Surface mount
6 - 17
[MAIN UNIT]
MIC
IC1
1130008990
S.IC
LC7366NM-TRM
T
Q1
1590003340
S.TRANSISTOR
DTA114EUA T106
T
D1
1730002500
S.ZENER
MA8062-M (TX)
T
X1
6060000700
S.CERAMIC
PRBC 3.58AR
T
L5
6200008620
S.COIL
LK1608-R82K-T
T
R1
7030009370
S.RESISTOR
MCR03EZHJ 220
Ω
— (221)
T
R13
7030009360
S.RESISTOR
MCR03EZHJ 100
Ω
— (101)
T
R14
7030009410
S.RESISTOR
MCR03EZHJ 2.2 k
Ω
— (222)
T
R15
7030009450
S.RESISTOR
MCR03EZHJ 5.6 k
Ω
— (562)
T
R17
7030009430
S.RESISTOR
MCR03EZHJ 3.3 k
Ω
— (332)
T
R18
7030009350
S.RESISTOR
MCR03EZHJ 10
Ω
— (11)
T
R19
7030009430
S.RESISTOR
MCR03EZHJ 3.3 k
Ω
— (332)
T
R20
7030009430
S.RESISTOR
MCR03EZHJ 3.3 k
Ω
— (332)
T
R22
7030009380
S.RESISTOR
MCR03EZHJ 470
Ω
— (471)
T
R23
7030009390
S.RESISTOR
MCR03EZHJ 1 k
Ω
— (102)
T
R24
7030009470
S.RESISTOR
MCR03EZHJ 47 k
Ω
— (473)
T
R25
7030009470
S.RESISTOR
MCR03EZHJ 47 k
Ω
— (473)
T
R26
7030009470
S.RESISTOR
MCR03EZHJ 47 k
Ω
— (473)
T
R27
7030009470
S.RESISTOR
MCR03EZHJ 47 k
Ω
— (473)
T
R28
7030009470
S.RESISTOR
MCR03EZHJ 47 k
Ω
— (473)
T
R29
7030009470
S.RESISTOR
MCR03EZHJ 47 k
Ω
— (473)
T
R30
7030009470
S.RESISTOR
MCR03EZHJ 47 k
Ω
— (473)
T
R31
7030009470
S.RESISTOR
MCR03EZHJ 47 k
Ω
— (473)
T
R35
7030009360
S.RESISTOR
MCR03EZHJ 100
Ω
— (101)
T
R36
7030011020
S.RESISTOR
MCR03EZHJ 330
Ω
— (331)
T
C1
4030014380
S.CERAMIC
UMK107 CH 200JZ-T
T
C2
4030014380
S.CERAMIC
UMK107 CH 200JZ-T
T
C3
4030014370
S.CERAMIC
LMK212 BJ 105KG-T
T
C4
4030014410
S.CERAMIC
TMK107 B 103KZ-T
T
C13
4030014370
S.CERAMIC
LMK212 BJ 105KG-T
T
C15
4030014400
S.CERAMIC
TMK107 B 102KZ-T
T
C16
4030014360
S.CERAMIC
EMK212 BJ 334KG-T
T
C17
4030014370
S.CERAMIC
LMK212 BJ 105KG-T
T
C18
4030018730
S.CERAMIC
C1608 JB 1E 104K-T
T
C19
4030014390
S.CERAMIC
UMK107 SL 470JZ-T
T
C20
4030014400
S.CERAMIC
TMK107 B 102KZ-T
T
C21
4030014410
S.CERAMIC
TMK107 B 103KZ-T
T
C22
4030014400
S.CERAMIC
TMK107 B 102KZ-T
B
C24
4030014400
S.CERAMIC
TMK107 B 102KZ-T
B
C25
4030014400
S.CERAMIC
TMK107 B 102KZ-T
B
C26
4030014400
S.CERAMIC
TMK107 B 102KZ-T
T
C28
4030014390
S.CERAMIC
UMK107 SL 470JZ-T
T
C29
4030014390
S.CERAMIC
UMK107 SL 470JZ-T
T
J1
6510021010
CONNECTOR
52018-8835
T
DS1
5040002380
S.LED
SML-311YT T86
B
DS2
5040002380
S.LED
SML-311YT T86
B
DS3
5040002380
S.LED
SML-311YT T86
B
DS4
5040002380
S.LED
SML-311YT T86
B
MC1
7700002410
MICROPHONE
KUB2823-011500
B
S1
2230001020
S.SWITCH
JPM1990-2013R
T
S2
2220000620
S.SWITCH
SSSS81560A
T
S3
2260002500
SWITCH
SKHHLM
T
S4
2260002500
SWITCH
SKHHLM
T
W1
8900007971
CABLE
OPC-762A
T
EP1
0910057261
PCB
B 6021A
REF
ORDER
DESCRIPTION
M.
NO.
NO.
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
