QuickSpecs

Compaq Armada M300

DA-10381

World Wide — Version 20 — June 29, 2001

Technical Specifications

Applicable Disk

CD-ROM (Mode 1, 2 and 3), CD-XA ready (Mode 2, Form 1 and 2), CD-I ready
(Mode 2, Form 1 and 2), CD-R (read only), CD Plus, Photo CD (Single and Multi-
session),
CD-Extra, Video CD, CD-WO (fixed packets only),
CD-Bridge

Center Hole Diameter

0.59 in/15 mm

24X Max CD-ROM Drive
(Supported in optional MEU)

Disk Diameter

12 cm, 8 cm

Disk Thickness

1.2 mm

Track Pitch

1.6 µm

Access Times (typical reads,
including settling)

Random

< 150 ms

Full-Stroke

< 300 ms

Audio Output Level

Line-out 0.7

Vrms

Cache Buffer

128 KB/s (minimum)

Data Transfer Rate (typical,
including settling)

Sustained (16X)

150 KB/s (sustained 1X)

Variable

1500 to 3600 KB/s (10X to 24X)

Normal PIO Mode 4 (single
burst)

16.66 MB/s

Start-up Time

< 8 sec

Stop Time

< 4 sec
