Green & Yellow

- Earth

Blue

- Neutral

Brown

- Live

As the colours of the wires in the mains lead may not
correspond with the coloured markings identifying the
terminals in your plug, proceed as follows:
Connect the Green & Yellow wire to terminal marked
“E” or

or coloured Green or Green & Yellow.

Connect the Brown wire to the terminal marked “L” or
coloured Red.
Connect the Blue wire to the terminal marked “N” or
coloured Black.

Replacing the cable
Use a rubber cable of the type H07RN-F with a
suitable cross section 3 x 6 mm².
The yellow-green earth wire must be 2-3 cm longer
than the other wires.

TECHNICAL DATA (1

Oven )

Oven dimensions

H:34;W:38;D:44 cm

Volume

54 Lt

Voltage and frequency

see data plate

ENERGY LABEL

Directive 2002/40/EC on the
label of electric ovens.
Regulation EN 50304

Energy consumption for Natural
convection – heating mode:

Traditional mode

;

Declared energy consumption
for Forced convection Class –
heating mode:

Multi cooking Mode.

EC Directives: 2006/95/EEC
dated 12/12/06 (Low Voltage)
and subsequent amendments -
89/336/EEC dated 03/05/89
(Electromagnetic Compatibility)
and subsequent amendments -
93/68/EEC dated 22/07/93 and
subsequent amendments -
2002/96/EC.

TECHNICAL DATA (2

Oven)

Dimensions

H:33.8;W:24.5;D:43.8 cm
