Air Cooled
Please note: air-cooled units require 6" (152 mm) clearance
for air intake and exhaust.
A. Ice maker potable water in, 3/8" FPT.
B. Ice maker water out, 3/4" FPT.
C. Hole for electrical connections, 7/8".
D. Electrical connection junction box.
Air In–
Rear
Standard Side
Discharge
30"
(762mm)
24
20" (508 mm)
24"
(610mm)
Optional Top Discharge– No Side Clearance Required
B.
C.
D.
A.
2.6"
(67 mm)
.7" (18 mm)
5" (127mm)
Bin Straps
5" (127mm)
Bin Straps
.62" (16mm)
14.3" (363 mm)
11.7" (297 mm)
Air Cooled
Water Cooled/Remote
A. Ice maker potable water in, 3/8" FPT.
B. Ice maker water out, 3/4" FPT.
C. Hole for electrical connections, 7/8".
D. Electrical connection junction box.
E. Condenser water in, 3/8" FPT (water only).
F. Condenser water out, 1/2" FPT (water only).
G. Liquid line, 3/8" male quick connect
coupling for precharged line set
(remote only).
H. Discharge line, 1/2" male quick connect
coupling for precharged line set
(remote only).
I. Hole for remote connections, 7/8"
(remote only).
.70"(18 mm)
2.6"(67 mm)
14.5" (368 mm)
7.5"
(191 mm)
10.5"
(267 mm)
11.7" (297 mm)
6.5" (165 mm)
E.
D.
F.
B.
C.
A.
3.5" (89 mm)
G. H.
3.0" (76 mm)
I.
Water Cooled & Remote
Operating Requirements
Minimum Maximum
60 Hz 50Hz
Ambient Temp. Range Air 50˚F (10˚C) 100˚F (38˚C) 110˚F (43˚C)
Water Temp. 40˚F (4.4˚C) 100˚F (38˚C) 110˚F (43˚C)
Water Pressure 20 PSIG (1.4 BAR) 60 PSIG (4.1 BAR)
Dimensions
All Models
W x D x H (inches) 30 x 24 x 20
W x D x H (mm) 762 x 610 x 508
Specifications
Model Number Cond. Unit
Ice Production
per 24hrs Water Usage
gallons per 100 lbs of Ice
90°F air/70°F water
kWH Used
per 100 lbs
of ice @
90°F air/
70°F water
Voltage
Characteristics
Min.
Circuit
Ampacity Fuse Size
Approx.
BTUs
per hour
70°F air/
50°F water
lbs (kg)
90°F air/
70°F water
lbs (kg) Potable Condenser
ICE0605A Air 636 (289) 459 (209) 22.0 - 5.8 230/50/1 9.9 16 9,523
ICE0605R Remote* 555 (252) 474 (215) 27.9 - 6.2 230/50/1 10.3 16 10,138
ICE0605W Water 609 (277) 523 (238) 24.3 114 4.6 230/50/1 7.4 16 9,684
ICE0606A Air 652 (296) 506 (230) 25.2 - 5.9 208-230/60/1 11.5 15 10,566
ICE0606T Air 652 (296) 505 (230) 25.8 - 6.2 208-230/60/1 10.4 15 10,884
ICE0606R  Remote* 605 (275) 502 (228) 24.9 - 6.3 208-230/60/1 12.9 15 10,850
ICE0606W Water 619 (281) 576 (262) 29.0 148 4.7 208-230/60/1 8.7 15 10,767
*Requires VRC 1061 Remote Condenser and precharged line set
