iHome iH70 User Manual
Page 5
Raise Volume Button
Lower Volume Button
iPod sync mode LED
Power Button
USB Jack
Headphone Jack
Aux-in Jack
To Computer
audio Jack
iPod sync Button
DC Jack
Right Speaker Jack
To left
speaker Jack
iPod Dock
2
Controls and Indicators
Front Panel
Back Panel
Side Left
Speaker Panel
Left Speaker
Right Speaker
Left Speaker
Right Speaker
Power LED
Stand
