iOptron SMARTSTAR CUBE 8603 User Manual
Page 6

6
1.2. Assembly Terms
1. Telescope tube
2. Dovetail lock
3. Hand controller
4. Altitude lock
5. Mount
6. Tripod
7. Tripod shaft
8. Tray
9. Tray lock
10. Azimuth lock screw
11. Wedge tilt screw
12. Tilt locks
13. Counterweight and shaft (not included)
5
6
7
8
9
10
13
11
12
Polaris
Zenith
Figure 1. Assembly Terms
