Ice-O-Matic ICE0606A3-T3-W3-R4 - Manual (Page 5)

ICE Series Service Parts Cabinet Assembly
Item Model Number
No. ICE0250 ICE0400 ICE0406 ICE0500 ICE0606 Description
1 2101285-01 2101285-01 2101285-01 2101285-01 2101285-01 Top Panel-Air Cooled
1 2101280-01 2101280-01 2101280-01 2101280-01 2101280-01 Top Panel-Top Discharge
1 9051466-01 9051466-01 9051466-01 9051466-01 9051466-01 Top Panel-Water Cooled and Remote
2 9031098-02 9031098-02 9031098-02 9031098-02 9031098-02 Top Panel Screw
3 2031465-01 2031465-01 2031465-01 2031465-01 2031465-01 Front Panel
4 9031098-02 9031098-02 9031098-02 9031098-02 9031098-02 Front Panel Screw
5 3021915-01 3021915-01 3021915-01 3021915-01 3021915-01 Left Hand Side Panel
6 9031046-03 9031046-03 9031046-03 9031046-03 9031046-03 Side Panel Screws
7 9031141-01 9031141-01 9031141-01 9031141-01 9031141-01 Plastic Nut Insert
8 2031504-01 2031504-01 2031504-01 2031504-01 2031504-01 Right Hand Side Panel-Louvered
9 3012681-01 3012681-01 3012681-01 3012681-01 3012681-01 Junction Box Cover
10 9031046-01 9031046-01 9031046-01 9031046-01 9031046-01 Junction Box Cover Screw
11 3021914-01 3021914-01 3021914-01 3021914-01 3021914-01 Right Hand Side Panel Non-Louvered
12 3021742-01 3021742-01 3021742-01 3021742-01 3021742-01 Rear Panel
13 9031046-01 9031046-01 9031046-01 9031046-01 9031046-01 Rear Panel Screw
14 3012905-01 3012905-01 3012905-01 3012905-01 3012905-01 Control Box Top Cover
15 3012904-01 3012904-01 3012904-01 3012904-01 3012904-01 Control Box Side Cover
16 9031046-01 9031046-01 9031046-01 9031046-01 9031046-01 Control Box Screws
17 N/A N/A N/A N/A N/A N/A
18 3012855-01 3012855-01 3012855-01 3012855-01 3012855-01 Control Box Front Cover
19 2021650-01 2021650-01 2021650-01 2021650-01 2021650-01 Left Hand Frame Side
20 2021648-01 2021648-01 2021648-01 2021648-01 2021648-01 Divider Base Assembly
21 2021649-01 2021649-01 2021649-01 2021649-01 2021649-01 Right Hand Frame Side
22 9131181-01 9131181-01 9131181-01 9131181-01 9131181-01 Insulation
23 9131121-04 9131121-04 9131121-04 9131121-04 9131121-04 Insulation
24 9031154-01 9031154-01 9031154-01 9031154-01 9031154-01 Retainer "Christmas Tree Clip"
25 3012724-01 3012724-01 3012724-01 3012724-01 3012724-01 Brace
Item Model Number
No. ICE0305 ICE0405 ICE0605 Description
1 2101285-01 2101285-01 2101285-01 Top Panel-Air Cooled
1 2101280-01 2101280-01 2101280-01 Top Panel-Top Discharge
1 9051466-01 9051466-01 9051466-01 Top Panel-Water Cooled and Remote
2 9031098-02 9031098-02 9031098-02 Top Panel Screw
3 2031465-01 2031465-01 2031465-01 Front Panel
4 9031098-02 9031098-02 9031098-02 Front Panel Screw
5 3021915-01 3021915-01 3021915-01 Left Hand Side Panel
6 9031046-03 9031046-03 9031046-03 Side Panel Screws
7 9031141-01 9031141-01 9031141-01 Plastic Nut Insert
8 2031504-01 2031504-01 2031504-01 Right Hand Side Panel-Louvered
9 3012681-01 3012681-01 3012681-01 Junction Box Cover
10 9031046-01 9031046-01 9031046-01 Junction Box Cover Screw
11 3021914-01 3021914-01 3021914-01 Right Hand Side Panel Non-Louvered
12 3021742-01 3021742-01 3021742-01 Rear Panel
13 9031046-01 9031046-01 9031046-01 Rear Panel Screw
14 3012905-01 3012905-01 3012905-01 Control Box Top Cover
15 3012904-01 3012904-01 3012904-01 Control Box Side Cover
16 9031046-01 9031046-01 9031046-01 Control Box Screws
17 3012931-01 3012931-01 3012931-01 Machine Compartment Cover
18 3012855-01 3012855-01 3012855-01 Control Box Front Cover
19 2021650-01 2021650-01 2021650-01 Left Hand Frame Side
20 2021648-01 2021648-01 2021648-01 Divider Base Assembly
21 2021649-01 2021649-01 2021649-01 Right Hand Frame Side
22 9131181-01 9131181-01 9131181-01 Insulation
23 9131121-04 9131121-04 9131121-04 Insulation
24 9031154-01 9031154-01 9031154-01 Retainer "Christmas Tree Clip"
25 3012724-01 3012724-01 3012724-01 Brace
Page 3
