The hob burners do not require primary air adjustment.

After adjusting the appliance so it may be used

with a different type of gas, replace the old rating

label with a new one that corresponds to the new

type of gas (these labels are available from

Authorised Technical Assistance Centres).

Should the gas pressure used be different (or vary

slightly) from the recommended pressure, a suitable

pressure regulator must be fitted to the inlet hose in

accordance with current national regulations relating

to regulators for channelled gas.

Adapting the oven

Replacing the oven burner nozzle:

1. Remove the oven compartment.

2. Slide out the protection

panel A

(see diagram).

3. Remove the oven burner

after unscrewing the screws V

(see figure).

The whole operation will be

made easier if the oven door

is removed.

4. Unscrew the nozzle using a

special nozzle socket spanner

(see figure) or with a 7 mm

socket spanner, and replace it

with a new nozzle that is

suited to the new type of gas

(see Burner and nozzle

specifications table).

Adjusting the gas oven burners minimum setting:
1. Light the burner (see Start-up and Use).

2. Turn the knob to the minimum position (MIN) after

it has been in the maximum position (MAX) for

approximately 10 minutes.

3. Remove the knob.

4. Tighten or loosen the adjustment screws on the

outside of the thermostat pin (see figure) until the

flame is small but steady.

If the appliance is connected to liquid gas, the

adjustment screw must be fastened as tightly as

possible.

5. Turn the knob from the MAX position to the MIN

position quickly or open and shut the oven door,

making sure that the burner is not extinguished.

Adapting the grill

Replacing the grill burner nozzle:

1. Remove the oven burner

after loosening screw V (see

figure).

2. Unscrew the grill burner

nozzle using a special nozzle

socket spanner (see figure) or

preferably with a 7 mm socket

spanner, and replace it with a

new nozzle that is suited to the

new type of gas (see Burner

and nozzle specifications table).

Be careful of the spark plug wires and the

thermocouple tubes.

The oven and grill burners do not require primary

air adjustment.
