IOGear MINIVIEW GCS1774 - Manual (Page 3)

Keyboard USB
Monitor HDB-15
Peripherals USB 2.0 port
**** Unit Dimensions
Width 3.5 in
Height 2.19 in
Length 10.63 in
Weight
Unit Pack Wt. 5.51 lbs
Unit Wt. 2.03 lbs
Master Carton Wt. 18.74 lbs
Housing
Case Metal
Power
Voltage 1 x DC 5.3V; 2.4A
Console Connectors
Keyboard 1 x USB Type A female
Mouse 1 x USB Type A female
Audio 1 x speaker; 1 x mic
Flash ROM Upgrade 1 x RJ-11
Monitor 1 x HDB-15 female
LEDs
LAN 5 (green)
Link 5 (green)
USB Peripherals 2 (green)
Computer Connections
Direct 4
*** Unit Package Dimensions
Width 8.35 in
Length 12.91 in
Height 3.98 in
* Master Carton
Height 9.17 in
Width 12.76 in
* Master Carton Qty. 3
Depth 13.58 in
© 2006 IOGEAR, Inc. All other trademarks belong to the respective owners.
