www.ifoundrysys.com

Doc. P/N: MDMA01479

Rev. 1.80

© 2007 iFoundry Systems

19 Apr 2007

Specifications subject to change

IFSYS-7000 IrDA

TM

SIR Endec Chip (SOP8)

Product Brief

SPECIFICATIONS

Hardware features

…

8-pin SOP (surface mount) package

…

Single power supply (2.7V – 5.5V supply)

Supported speeds

…

Using external 16X clock from UART:

9,600bps

19,200bps

38,400bps

57,600bps

115,200bps

Electrical characteristics

…

Temperature:

Operating: -40

o

C to +85

o

C

Storage: -65

o

C to +150

o

C

…

Current consumption:

1.5mA (typ.), 6mA (max.) [2MHz on 16X clock input]


Dimensions

…

SOP8 package: 6.65mm (W) x 5.60mm (L) x 1.55 mm (H)

…

Weight: ~0.2g


Packaging options

…

Tape and reel

…

Tube


Ordering Information

Order Number

Order Description

IFSYS-7000A:6101

IC in Tube packaging

IFSYS-7000A:7101

IC in tape and reel packaging

IrDA

TM

is a trademark of the Infrared Data Association.

iFoundry Systems Singapore
67 Ayer Rajah Crescent
Unit 03-20/22
Singapore 139950

For more information:
Email:

[email protected]

Web: www.ifoundrysys.com
