I/OMagic PC PVR
User’s Guide
- 12 -
7 Install the I/OMagic PC PVR video capture card into the card slot
Place the card over the expansion slot with the mounting bracket facing the
access slot (the same slot you removed the cover plate from). Carefully
align the connector with the slot and push the card into the slot until it
snaps into place. You may need to use a gentle back-and-forth rocking
motion when inserting the card into the slot. Once you install the card,
secure it by replacing the screw you removed with the expansion slot cover
plate.
Double-check all connections, make sure everything is
plugged in correctly and firmly seated before you replace the
cover.
