Operation

Connecting the Projector

Due to the

difference in

applications for each

country, some regions

may have different

accessories.

To ensure the projector works well with your computer,

please make sure the timing of the display mode is

compatible with your projector.

1................................................................................................................RS232 cable

2...............................................................................................................HDMI cable

3.............................................................................................................VGA in cable

4............................................................................................ Composite video cable

5...........................................................................................Audio cable jack to jack

6........................................................................ RCA Component Cable for YPbPr

7............................................................................................................ S-Video cable

8................................................................................................................ Power cord

DVD player, Set-top Box

HDTV receiver

VGA, DVI

Video Output

RS232

DVD player, Set-top Box

HDTV receiver

S-Video Output

1

2

3

5

7

6

4

8

5
