IOD 16022 and 22030 Service Parts Cabinet Front
IOD 16022 and 22030
IOD16022 IOD22030
Item Number Description Part Number Part Number
1 Cover, Merch. Black-Lever 30064206 30064226
Cover, Merch. Black-Push Button 30064218 30064238
Screws For Cover 30069901 30069901
2 Merch. Sign 3015075218 3015075418
3 Bezel for Ice Switch Button 3002307101 3002307101
4 Button, Ice Switch 3002307200 3002307200
5 Push Button Switch Bracket 30072700 30072700
6 Microswitch (Push Button) 30073000 30073000
6 Microswitch (Lever) 3012157001 3012157001
7 Ice Chute 3002306801 3002306801
8 Ice Chute Panel 30072800 30072830
9 Grill/Cup rest 3000570132 30077031
10 Black Drain Pan Assembly 30061102 30061122
11 Panel, Lever 3A34794005 3A34795009
Panel, Push Button 3034794006 3A34795010
12 Splash Panel 30061810 30076010
13 Screw 30073200 30073200
14 Boot For Microswitch 3012237201 3012237201
15 Lever (Lever Models Only) 3A34806001 3A34806001
16 Thumbscrew 3003072706 3003072706
Page 5
