1.2. SmartStar
®
R-80 Assembly Terms
1. Telescope
2. Dovetail Lock
3. Hand Controller
4. Altitude Lock
5. Mount (GPS model)
6. Diagonal
7. Eyepiece
8. Height Adjustment Handle
9. Tripod Lock Knob
10. Tripod Leg Lock
11. Tripod
12. Height Extender Lock
13. Height Extender
5
11
13
8
6
12
7
9
10
5
11
13
8
6
12
7
9
10
