Ironman Fitness Envision - Manual (Page 5)

5
Assembly: Parts Identifier
The Ironman Envision Treadmill will require assembly before operating. Place unopened box
on a clean, level surface. After opening the box, remove any packing material from the tread-
mill.
Do not throw away any packing materials until the unit is working properly.
Do not remove unit from box until it has been fully assembled.
Make sure the electrical cord will easily reach an electrical outlet.
If at anytime you need assistance with assembly, call 888-559-8810.
Identify the following parts required for assembly.
LEFT OUTSIDE FENDER
LEFT INSIDE FENDER
RIGHT OUTSIDE FENDER
RIGHT INSIDE FENDER
LEFT OUTSIDE HANDLE COVER
RIGHT OUTSIDE HANDLE COVER
LEFT UPPER HANDLE COVER
RIGHT UPPER HANDLE COVER
LEFT LOWER HANDLE COVER
RIGHT LOWER HANDLE COVER
PHILIP SCREW ST4.2*16
22 PCS
SCREW
DRIVER MULTI-TOOL ALLEN
WRENCH
WASHER Φ9*Φ22*2
ALLEN BOLT M8*30
ALLEN BOLT M8*15
ALLEN BOLT M8*20
