GCS661U Diagram
No
Component
Description
1
USB Plug
This end connects to the USB port on the Remote computer (note the
longer length of the cord).
2
LED
Flashes blue at a slow, steady pace when connection between both
computers is working or when the device is idle.
Flashes blue at a rapid pace when data is being transferred between
both computers.
3
USB Plug
This end connects to the USB port on the Local computer (note the
shorter length of the cord).
4
USB 2.0 Peripheral Port
USB 2.0 peripherals port.
