IBM ® ThinkPad ® T41 (2378) - Express - withdrawn
Perfect balance of performance and portability; two-spindle system
Intel ® Pentium ® M Processor 1.4GHz with
enhanced Intel SpeedStep ™ technology 1 and 400MHz system bus
1MB / on die (at processor speed) / ECC
256MB standard / 2GB max 7 / PC2700 333MHz DDR-SDRAM / non-parity / CL2.5 /
two 200-pin SO-DIMM sockets / std mem in one socket / one socket available
None standard / use optional USB-based diskette drive
Some: DVD-ROM / 24X-8X
8 speed / bootable / removable from Ultrabay ™ Slim
Some: DVD-ROM/CD-RW / 16X/10X/24X/8X 21 speed / removable from Ultrabay Slim
One modular bay for interchangeable devices (right side) / 9.5mm high bay
30GB 8 (4200 rpm) or 40GB HS (5400 rpm) / 9.5mm high / removable and upgradable /
9.5mm high bay / supports 2nd disk with optional HDD Adapter in Ultrabay Slim /
IBM Hard Disk Drive Shock Absorber /
IBM Active Protection System (shock protection)
Some: 14.1" (358.1mm) XGA (1024x768) TFT color / Active Matrix / 150 nits
Some: 14.1" (358.1mm) SXGA+ (1400x1050) TFT color / Active Matrix / 150 nits
Some: ATI ® Mobility RADEON ® 7500 / AGP 4X / 32MB DDR-SDRAM
Some: ATI Mobility RADEON 9000 / AGP 4X / 32MB DDR-SDRAM
External monitor support via analog DB-15 connector / up to 2048x1536x16.7M at 75Hz
87-key / Access IBM button / palm rest / pitch: 19mm; stroke: 2.5mm (std-size keys)
TrackPoint
® pointing device, "Press-to-Select," Internet Scroll Bar 13 , magnifying glass /
UltraNav ™ multi-pointing system / touch pad below keyboard / Tap Zones
Illuminates the keyboard to improve visibility in low-light conditions
(WxDxH): 12.2" x 10.0" x 1.0-1.2"; 311mm x 255mm x 26.6-31.4mm
with optical drive and battery:
DFU/DGU/DHU: 4.9 lb (2.2 kg); DEU: 5.0 lb (2.2kg)
Magnesium composite in the top cover, titanium-reinforced CFRP in bottom cover
Lithium Ion 6-cell or 9-cell / intelligent / supports unique 2nd battery in Ultrabay Slim
6-cell models: 4.7 to 5.0 hr; Optional 9-cell: 7 hr; 9-cell plus Ultrabay Slim battery: 9 hr
Intel 855PM chipset / 82855PM Memory Controller Hub (MCH-M) /
82801DBM ICH4-M I/O Controller Hub (ATA-100 EIDE, PCI bus, ethernet MAC,
Low Pin Count [LPC] interface, USB, [Bluetooth]) / PCI bus 2.2 32-bit, 33MHz (TI
®
PCI4520A CardBus and 1394 controller, Mini PCI, external expansion) / LPC bus 33MHz
(security chip; PC87392 Super I/O for diskette, parallel, infrared, [docking-based ports])
2 Type I, 2 Type II, or 1 Type III / CardBus 32-bit / PCMCIA 2.1
Two USB (Version 2.0) / parallel / external DB-15 monitor / infrared (4Mbps) /
RJ-11 (modem) / RJ-45 (ethernet) / no keyboard or mouse or serial ports (use USB)
S-video out port (TV out) / one 4-pin industry standard connector
UltraConnect
™ Antenna built into the display cover for optimal wireless signal reception
One Mini PCI type III slot (Communications Bay) / customer upgradable
Some: wireless upgradable with wireless Mini PCI options
Some: 11b Wi-Fi
32 wireless 4 , Mini PCI, Intel PRO/Wireless 2100 Network Connection
802.11b, Intel 82531 chipset
One Communications Daughter Card (CDC) socket / customer accessible
56K
6 V.90 (V.92-designed 29 ) modem in CDC / Agere ® chipset
None
Gigabit ethernet on systemboard / Intel 82540EP chipset (MAC/PHY) / PXE
Soft audio / ICH AC97 controller / DirectSound
® support / AD1981B AC97 codec /
stereo speakers / 1 watt / volume up, down, mute buttons / internal mic /
microphone input jack (3.5 mm; pink) / headphone jack (3.5 mm; green)
Power-on password / hard disk password / supervisor password / security keyhole
IBM Embedded Security Subsystem 2.0 33 / hardware key storage / multi-factor
authentication / local file encryption / enhances VPN security 16 / TCG-compliant
1 year - EasyServ ™ ,19 onsite pickup and delivery courier serv / service upgrades 22 avail
Positioning
Processor
L2 cache
Memory
Diskette drive
DVD
Combo
Ultrabay Slim
Disk
Display
Graphics controller
Graphics - external
Keyboard
TrackPoint
®
Touch pad
ThinkLight
™
Dimensions 3
Approximate weight 2
Case material
Battery - type
Battery - life
10
Architecture
PC Card Std slots
Ports
Video out
Wireless antenna
Mini PCI
Wireless upg 36
11b Wi-Fi 32
CDC
Modem
Bluetooth
™
Ethernet
Audio support
Security
Security chip
Limited warranty 12
Universal 72 watt AC adapter
Asset ID
™ ,34 (system-specific info in
chip accessed over network)
PC 2001-compliant
ACPI 1.0b and 2.0-compliant
CIM and DMI 2.0-compliant
PXE 2.0-compliant
IBM ImageUltra
™ Services available
IBM Rapid Restore Ultra available to
protect software image and data
International Warranty Service 17
24 hour x 7 day 18 toll-free hardware
support during the warranty 12
SOFTWARE 14
Windows XP Pro models
- Microsoft ® Windows ® XP
Professional 20
✧Disk-to-Disk Recovery
(in hidden protected area)
Preloaded (all)
• Access IBM
• Access Connections
• Adobe Acrobat Reader
• IBM Rapid Restore™ Ultra
• IBM RecordNOW and IBM Drive
Letter Access (combo models)
• InterVideo WinDVD (combo mdls)
• Norton AntiVirus (OEM edition)
• PC-Doctor™
• ThinkPad Utilities
• IBM Update Connector™ ,15
Downloadable
• IBM Director Agent
• Software Delivery Assistant
• System Migration Assistant
• Client Security Software (for
security chip)
License (CD not included)
- Lotus ® SmartSuite ® Millennium and
Lotus Notes ® Stand-alone Client
2378-DEU Pentium ® M 1.4 256MB 14.1” SXGA+ 9000 30GB DVD Open; wireless upg 36 Modem Gigabit Yes 6 XP Pro 1 yr Oct 2003
2378-DFU Pentium M 1.4 256MB 14.1” XGA 7500 40HS DVD Open; wireless upg Modem Gigabit Yes 6 XP Pro 1 yr Oct 2003
2378-DGU Pentium M 1.4 256MB 14.1” XGA 7500 40HS Combo Open; wireless upg Modem Gigabit Yes 6 XP Pro 1 yr Oct 2003
2378-DHU Pentium M 1.4 256MB 14.1” XGA 7500 40HS Combo ✳Intel 11b Wi-Fi 32 Modem Gigabit Yes 6 XP Pro 1 yr Oct 2003
Type-model Processor
Speed
GHz Screen Memory
Disk
GB 8 Optical
Mini PCI
Comm Bay
wireless
Security
chip
CDC
modem/
Bluetooth TM Preload
Avail
date
Created by IBM PC Institute
Personal Systems Reference (PSREF)
Ethernet
on
planar
Graphics
controller
See footnotes for important warranty information
✳
Powered by Intel Centrino
™
mobile technology
US models announced October 7, 2003
US models withdrawn effective July 2004
(T41B1) © IBM Corp. July 2004
Limited
Warranty
Battery
cells
•
These small and medium business (SMB) models are part of the IBM US Think Express Program
• The 2378 has a 1 year limited warranty (other ThinkPad T41 2379 models have a 3 year limited warranty)
ServicePac ®, 22 1yr IOR 9x5 NBD
30L9188
ServicePac 2 yr IOR 9x5 NBD
30L9189
ServicePac 3 yr IOR 9x5 NBD
30L9195
ServicePac 4 yr IOR 9x5 NBD
30L9194
ServicePac 5 yr IOR 9x5 NBD
30L9196
ServicePac 2 yr P&L P/U Depot
30L9191
ServicePac 3 yr P&L P/U Depot
30L9192
ServicePac 4 yr P&L P/U Depot
69P9195
ServicePac 5 yr P&L P/U Depot
69P9197
Other ServicePac options at
ibm.com /services/its/us/source/
wamomxeu.pdf
Post-warranty annual maintenance
agreements at
ibm.com /services/its/us/source/
maspspleu.pdf
ThinkPad T40 Li-Ion Battery 6-cell 08K8214
T40 High Capacity Li-Ion Battery 9-cell 08K8197
Ultrabay Slim Li-Polymer Battery 3-cell 08K8190
ThinkPad Multiple Battery Charger II
22P9040
ThinkPad 72W AC Adapter 02K6699
ThinkPad 72W AC/DC Combo Adapter 22P9010
IBM 11a/b/g Wireless CardBus Adapter 31P9101
IBM 11a/b/g Wireless Mini PCI Adapter 31P9701
Intel PRO/Wireless 2200BG Mini PCI
73P2801
Cisco Aironet Wireless 802.11b Mini PCI 31P8301
GemPC400 Smart Card Reader/Writer
31P8901
ThinkPad Port Replicator II 74P6733
ThinkPad Mini Dock 287810U
ThinkPad Dock II 287710U
Kensington ® MicroSaver ® Security Cable73P2582
Other options at ibm.com /pc/us/accessories
128 MB PC2700 DDR-SDRAM CL2.5 SOD 31P9828
256 MB PC2700 DDR-SDRAM CL2.5 SOD 31P9830
512 MB PC2700 DDR-SDRAM CL2.5 SOD 31P9832
1GB PC2700 DDR-SDRAM CL2.5 SOD
31P9834
IBM USB Portable Diskette Drive 05K9276
IBM USB 2.0 Portable CD-RW Drive 22P5297
IBM USB 2.0 Portable Combo Drive 22P9194
CD-RW/DVD Combo II Ultrabay Slim Drive 73P3288
ThinkPad DVD-ROM Ultrabay Slim Drive
73P3270
Second HDD Adapter for Ultrabay Slim 62P4554
30GB Hard Disk 9.5mm (4200 rpm) 09N4268
40GB HS Hard Disk 9.5mm (5400 rpm) 08K9816
80GB Hard Disk 9.5mm (4200 rpm) 08K9869
IBM 4GB Microdrive ™ with PC Card 09N4280
IBM 256MB USB 2.0 Memory Key 22P9025
IBM Optical 3-Button Travel Wheel Mouse 31P7410
