Instructions for model s120–eu circular air saw

background image

Refer All Communications to the Nearest
Ingersoll–Rand Office or Distributor.

Ingersoll–Rand Company 1999

Printed in U.S.A.

03531456

Form P6566–EU
Edition 7
October, 1999

INSTRUCTIONS FOR

MODEL S120–EU CIRCULAR AIR SAW

The Model S120–EU Air Circular Saw, when used with the proper blade, can be used by contractors
to cut concrete, granite, heavy sections of aluminum, steel tubing, timbers, planking, etc. Because
there are no electrical cables, these saws are ideally suited for shipyard work and wet
environments.
Ingersoll–Rand is not responsible for customer modification of tools for applications on which
Ingersoll–Rand was not consulted.

IMPORTANT SAFETY INFORMATION ENCLOSED.

READ THIS MANUAL BEFORE OPERATING TOOL.

IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PLACE THE INFORMATION

IN THIS MANUAL INTO THE HANDS OF THE OPERATOR.

FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY.

PLACING TOOL IN SERVICE

Always operate, inspect and maintain this tool in
accordance with all regulations (local, state, federal
and country), that may apply to hand held/hand
operated pneumatic tools.

For safety, top performance, and maximum durability
of parts, operate this tool at 90 psig
(6.2 bar/620 kPa) maximum air pressure at the inlet
with 3/4” (19 mm) inside diameter air supply hose.

Operating at higher air pressure will result in
excessive speed and may result in injury.

Always turn off the air supply and disconnect the air
supply hose before installing, removing or adjusting
any accessory on this tool, or before performing any
maintenance on this tool.

Do not use damaged, frayed or deteriorated air hoses
and fittings.

Be sure all hoses and fittings are the correct size and
are tightly secured. See Dwg. TPD905–1 for a typical
piping arrangement.

Always use clean, dry air. Dust, corrosive fumes
and/or excessive moisture can ruin the motor of an air
tool and affect performance.

Use only lubricants recommended by Ingersoll–Rand.
Do not lubricate tools with flammable or volatile
liquids such as kerosene, diesel or jet fuel.

Do not remove any labels. Replace any damaged label.

USING THE TOOL

Always wear eye protection when operating or
performing maintenance on this tool.

Always wear hearing protection when operating this
tool.

Use other personal protective equipment such as
gloves, apron and helmet when necessary.

Keep hands, loose clothing and long hair away from
rotating end of tool.

Anticipate and be alert for sudden changes in motion
during start up and operation of any power tool.

Keep body stance balanced and firm. Do not
overreach when operating this tool. High reaction
torques can occur at or below the recommended air
pressure.

Tool accessories may continue to rotate briefly after
throttle is released.

Air powered tools can vibrate in use. Vibration,
repetitive motions or uncomfortable positions may be
harmful to your hands and arms. Stop using any tool
if discomfort, tingling feeling or pain occurs. Seek
medical advice before resuming use.

Always release throttle in case of energy supply
failure.

Use accessories recommended by Ingersoll–Rand.

Do not use in explosive atmospheres or on explosive or
flammable materials.

Do not cut into electrical cables. This tool is not
insulated against contact with electric power sources.

This tool is not designed for working in explosive
atmospheres.

This tool is not insulated against electric shock.

The use of other than genuine Ingersoll–Rand replacement parts may result in safety hazards, decreased tool
performance, and increased maintenance, and may invalidate all warranties.
Repairs should be made only by authorized trained personnel. Consult your nearest Ingersoll–Rand Authorized
Servicenter.

GB

TPD1214
