Ref
Part #
Description
Qty
Ref
Part #
Description
Qty
01FD 314-00001 LEFT STICKER 600E
3
2GTU 313-00366 POWER SOURCE SPCKET, 600MM ACHIEVER
1
01FE 314-00002 RIGHT STICKER 600E
3
2GTW 313-00418 HARNESS, HAND PULSE 500MM
2
01HH 310-00115 BRAKE CABLE, CG
1
2GVA 313-00369 REED SWITCH, ACHIEVER/CDT
1
0J3P 302-01444 ALLEN WRENCH, REXON
1
2GVB 307-00133 AC ADAPTER, ACHIEVER/CDT/AEROS
1
0J3R 302-00142 WRENCH HEX. 6-83MM
1
2H4J 302-01349 RETAINING RING, ACHIEVER
1
0J4Z 302-01294 FLAT WASHER, 12X20-3
4
2H66 302-01348 M10*1.5-210, HEX HEAD BOLT
1
0J6C 302-00101 FLAT WASHER 10*20-2MM
3
2H7B 306-00693 SLEEVE ASSY, ACHIEVER
1
0J93 302-01307 SPRING WASHER, M10, BLACK
4
2HDZ 302-01481 SCREW, HEX.SOC.TRUSS.HD M6X1.0X-10 ZINC
6
0J9C 302-01308 SPRING WASHER, M10, ZINC
2
2HG6 302-01482 BOLT, HEX.SOC.HD.CAP M8X1.25-16 ZINC HRC
6
0JEE 302-01346 C-RING, A-17
4
2HJB 306-00732 END CAP, LINKAGE CTM-9.2E
4
0JEG 302-00109 C-RING A-20
1
2HK7 306-00726 END CAP, CONSOLE TUBE AEROS
2
0JEJ 302-01296 C-RING A-25
2
2HMB 302-01483 NUT, CROWN M10X1.5 T=18 ZINC
3
0K2C 302-01293 HEX.SOCKET HD.CAP SCREWS M8X1.25-16
4
2HMC 302-01484 SCREW, HEX.SOC.TRUSS.HD M10X1.5-120 ZINC
3
0K2W 302-01131 BOLT M5*12
3
2HMD 302-01485 SCREWM HEX.SOC.HD.CAP, M8X1.25-16 ZINC
3
0K3X 302-01292 CR.RE. PAN HD. SCREW & WASHER M5*0.8-14
2
2HNU 311-00077 IDLER BELT TENSION ASSY, CENTER-G/CDT
1
0K4R 302-01291 CR.-RE. TRUSS HD. SCREW M5*0.8-12
9
2J4R 311-00098 MAGNETIC BRAKE ASSY, ADVENTURE
1
0K4T 302-01445 SCREW, CR.-RE. TRUSS HD. M5X0.8-20
24
2J6N 502-00016 DECAL GENERIC IRONMAN LOGO PAPER LARGE-
3
0K71 302-01473 CR.RE. TRUSS HD SCREW (COVER) CG1-HR
2
2J6P 502-00012 IRONMAN M-DOT PAPER STICKER - RED
1
0K94 302-00115 CR. RE. TRUSS HD. TAPPING SCREW M5*12-16
16
2J78 302-01486 BOLT, HEX.SOC.HD.CAP, M8X1.25-12 ZINC
8
0KNM 302-01287 HEX. NUT, M10X1.5 CT=8
4
2JAW 302-01476 WRENCH 17MM
1
0KQX 302-01490 NUT, M6X1.0 T=6 BLACK
2
2JAX 302-01477 CRESCENT WRENCH
1
0KR0 302-01285 LOCKING NUT, M12*1.75 T12
4
2JAY 302-01478 SCREWDRIVER E05KY
1
0KRK 302-00144 U-TYPE NUT M5-12MM
16
2K84 307-00728 D.C. MOTOR ASSY, ADVENTURE
1
20W4 302-01284 HEX. NUT M10*1.5 T6, BLACK
2
2KX7 331-00105 BALL BEARING, 6203ZZ
4
21B8 302-01282 HEX. HD. BOLT M10*1.5-20, ZINC
2
2KX8 331-00106 BALL BEARING, 6204ZZ
2
21BA 302-01281 HEX. HD. BOLT M10*1.5-81.5
2
2KX9 331-00107 BALL BEARING, 6005ZZ
12
21K5 310-00187 MAGNET AND BRACKET, CENTER-G/ACHIEVER
1
2LGS 302-01474 BUSHING, CG1-HR
2
21X8 302-01304 SPACER, CENTER-G/ACHIEVER/CDT
3
2LXT 302-01455 BOLT, HEX. SOC. HD. CAP M12X1.75-55 BLAC
2
22LR 302-01401 C-RING, A-16 T=1.2 BLACK
1
2MPT 330-00098 CENTER SHAFT 90 DEGREE
1
22QV 302-01277 HEX. SOC. TRUSS HD. SCREW M10*1.5-20
4
2MPU 306-00815 COLLAR, ADVENTURE
2
22RR 302-01276 HEX. NUT M10*1.5,T8 ZINC
2
2MPV 302-01489 RETAINGING RING, ADVENTURE
2
240E 310-00216 HOLDER, WATER BOTTLE CG1-HR
1
2MPY 306-00808 GRIP, CG1
2
25VV 302-01347 C-RING, B-47 BLACK
6
2MPZ 319-00380 SHAFT WHEEL, WITH BEARING ADVENTURE
2
26LH 310-00204 LEVELER, CDT/ACHIEVER/CG2
4
2MQ1 319-00378 BRACKET, WHEEL RIGHT
1
27JR 302-01312 HEX. SOC SET SCREW, M5*6
4
2MQ7 306-00816 SHAFT SLEEVE, ADVENTURE
2
2874 331-00112 BALL BEARING, 6004ZZ ADVENTURE
8
2MQA 306-00817 LINKING SEAT, ADVENTURE
2
294S 302-01451 WASHER, FLAT 10X25-3 BLACK
2
2MQB 311-00099 DRIVE WHEEL, ADVENTURE
1
29Q7 306-00601 LEFT PEDAL, A7E,600E, NEW
1
2MQC 311-00100 DRIVE PULLEY, ADVENTURE
1
29Q8 306-00602 RIGHT PEDAL, A7E,600E, NEW
1
2MQJ 306-00819 END CAP, FRAME ADVENTURE
2
2AX2 306-00668 TRANSPORTATION WHEEL, CENTER-G
2
2MQV 319-00379 WHEEL BRACKET, LEFT ADVENTURE
1
2CU3 302-01301 CENTER SHAFT WASHER
2
2MQY 305-00228 COVER, SIDE RIGHT TOP, ADVENTURE
1
2CU7 302-01272 HEX. SOC. HD. CAP BOLT M12*1.75-30
4
2MSH 323-00567 CENTER SHAFT ASSY, ADVENTURE
2
2D2K 306-00680 FLYWHEEL COVER, (NEW STYLE) CENTER-G
2
2MSP 323-00566 CONSOLE MAST, ASSY ADVENTURE
1
2D3C 305-00150 SHAFT COVER RIGHT, CENTER-G
2
2MT4 304-00026 BELT, 450PJ
1
2D3E 305-00151 SHAFT COVER LEFT, CENTER-G
2
2MXF 306-00814 FOAM, ADVENTURE
2
2D3F 305-00152 BRACKET COVER, CENTER-G/ACHIEVER/CDT
2
2MXK 306-00818 BRAKE COLLAR, ADVENTURE
2
2DM4 302-01352 WASHER, HANDLEBAR 10.2MM IDX35MM
4
2N0P 307-00727 CONSOLE, ADVENTURE
1
2DUD 302-01382 SCREW, M5X0.8-12 CR.-RE. TRUSS HD ZINC
6
2N4W 314-00124 DECAL, ADVENTURE LOGO
1
2DZV 314-00027 CAUTION LABEL, CENTER-G
1
2N5A 323-00565 PEDAL TUBE ASSY, LEFT ADVENTURE
1
2GPW 305-00171 COVER, SIDE RIGHT INNER, ACHIEVER
1
2N5M 323-00564 HANDRAIL, UPPER ASSY LEFT ADVENTURE
1
2GPZ 305-00169 COVER, SIDE LEFT INNER, ACHIEVER
1
2N5N 323-00563 HANDRAIL, LOWER ASSY LEFT ADVENTURE
1
2GQS 305-00173 COVER, ACHIEVER
1
2N5P 323-00568 HANDRAIL, UPPER ASSY RIGHT ADVENTURE
1
2GS1 302-01472 PIN, CG1-HR
2
2N5Q 323-00569 HANDRAIL, LOWER ASSY RIGHT ADVENTURE
1
2GSJ 306-00727 HAND PULSE W/GRIP, AEROS
2
2N5R 323-00571 PEDAL TUBE ASSY, RIGHT ADVENTURE
1
2GSJ 306-00727 HAND PULSE W/GRIP, AEROS
2
2N5V 323-00572 LINKAGE ASSY, RIGHT ADVENTURE
1
2GTS 313-00416 WIRE, UPPER CONSOLE 2464X24AWGX1400MM
1
2N5W 323-00573 LINKAGE ASSY, ADVENTURE
2
2GTT 313-00417 LEAD WIRE ASSY, ASCENDER
1
2N5X 323-00570 HANDLE BAR ASSY, ADVENTURE
1
