IOGear GCS1784 User Manual
Page 11
11
No.
Component
Description
1
Firmware Upgrade Port Connection for the firmware up grade cable
2
USB Console Ports
USB1.0 Keyboard and mouse connections*
3
Console Port Section
Connections for your monitor, mike, and speakers
4
CPU Port Section
Connections for the cables that link the switch to your computers. Each
CPU port is comprised of a microphone jack, speaker jack, USB type B
socket and a DVI connector
5
Power Jack
Power adapter connection
6
USB Peripheral Port
Connection for USB 2.0 peripherals ( printers, scanners, etc)
