5
9. Plug in the male connectors on the PGHGM1 harness into the 16-pin port and
14-pin port on the back of the radio. Next, connect the factory 16-pin and 14-pin
harness into the female connectors on the PGHGM1 harness. Be sure to make a
firm connection but do not force it. Plug the Black micro-fit 24-pin connector on the
PGHGM1 harness into the PXAMG Media GateWay box.
10. To complete the installation secure the Media GateWay (PXAMG) and HD Radio
tuner (HDRT) or Satellite Radio tuner (SCC1) into the cavity in the dash behind
the radio. Be sure that the cables and interface modules are not near moving
parts or sharp metal edges as they may damage the cables. To prevent rattling
noises inside the dash, use zip ties, tape, or other fasteners to mount the
interfaces securely.
11. With all connections made, reconnect the vehicle’s battery, insert the key into the
ignition, and turn the vehicle on. Check for proper operation of the Media GateWay
and HD Radio tuner before reinstalling the factory dash panels.
12. Note: The first time you access the GateWay, your radio may display “DEV INIT”
while the device is initializing. If this is displayed, please wait one minute then
cycle the ignition off and on. Then access SAT mode again to begin normal
GateWay operation.
Non-Navigation Radios
6. iPod Operation
Entering Mode Select Menu
Press the “ BAND” button a few times until XM is displayed on the screen.
Immediately turn the rotary TUNE KNOB in the top right hand corner to scroll
through available sources. Once “IPOD” is displayed, press the “FWD>>” button
to select the displayed mode.
PLEASE NOTE: When entering the Mode Select menu for the first
time the radio will display “Busy” until the TUNE KNOB is turned.
Next Track
Turn the rotary TUNE KNOB clockwise one notch to advance to the next track.
Previous Track
Turn the rotary TUNE KNOB counter-clockwise one notch to move back to the previous
track.
Fast Forward
Press “►I SEEK” to fast forward the song that is playing. Press “►I SEEK”
again to resume play.
Rewind
Press “I◄ SEEK” to rewind the song that is playing. Press “I◄ SEEK” again to
resume play.
Entering Browse Menu / Select
Press the “FWD>>” button to enter the browse menu or to make a selection while in
the browse menu.
