Ice-O-Matic ICEU225 - Manual (Page 9)

ICE Undercounter Service Parts Control Box
Item Description ICEU150 ICEU220 ICEU225 ICEU226
1 Water Pump Connector 9101218-01 9101218-01 9101218-01 9101218-01
2 Terminal Block 9101037-01 9101037-01 9101037-01 9101037-01
3 Switch-Purge 9101139-03 9101139-03 9101139-03 9101139-03
4 Ice/Off/Wash Switch 9101195-01 9101195-01 9101195-01 9101195-01
5 Thermostat-Bin Control 9041004-02 9041004-02 9041004-02 9041004-02
6 Low Pressure Control (Timer Initiate) 9041094-01 9041094-01 9041094-01 9041094-01
7 High Pressure Control 9041095-01 9041095-01 9041095-01 9041095-01
8 Timing Module 9101148-01 9101148-01 9101148-01 9101148-01
9 Relay 9101084-01 9101084-01 9101084-02 9101084-02
10 Socket-Relay 9101083-01 9101083-01 9101083-01 9101083-01
11 Hold Down Spring - Relay 9101083-02 9101083-02 9101083-02 9101083-02
12 High Temperature Safety Control 9041087-03 9041087-03 9041087-03 9041087-03
R 8/06 Page 7
