TA3404 Owners Manual

Introduction

Thank you for choosing MTX to help reach your ultimate goal with your vehicle. Adding MTX ampliﬁers and

matching MTX speakers and subwoofers with StreetWires connections will put you in a better position to

hear, feel and experience all of the music the artist intended you to hear.

Speciﬁcations

Primary Ratings:

Power Output: 50 Watts RMS x 4 Channels at 4 Ohms and ≤ 1% THD+N

Signal-to-Noise Ratio (1Watt): 78dB

Secondary Ratings

Power Output: 100 Watts RMS x 4 Channels at 2 Ohms and ≤ 1% THD+N

Power Output: 200 Watts RMS x 2 Bridged at 4 Ohms and ≤ 1% THD+N

Power Output: 400 Watts RMS x 1 Bridged at 2 Ohms and ≤ 1% THD+N

THD+Noise (Distortion) (1Watt): ≤ .25%

Frequency Response (-3dB): 20Hz-20kHz

Maximum Input Signal: 10V

Maximum Sensitivity: 100mV

Dimensions: 9-5/8” x 12-11/16” x 2-1/2” (245mm x 325mm x 65mm)

Smart Engage Auto Turn-on (Patent No: US06556683)

Patented Pure N-Channel Technology (Patent No: US05631608, US05783970)

Patented Power Supply (US05598325)

Input Sensitivity Switch: 100mV-1V/1V-10V

Summed Front Rear Line Level Output

Crossover: Hi,12dB / Low, 24dB Mono @ 85Hz, Defeatable

Remote Subwoofer Level Control

Dual Mono Output (Low pass on 4 Ch)

Features

1. Prizm EFX – All MTX ampliﬁers include backlit adjustment controls on top surface of product.

• Color – The backlit controls offer unlimited colors on the display -- from RED, GREEN, BLUE, or any color

in between.

• EFX – You can switch Prizm EFX lighting to “pulsate” with beat of music.

2. Xtant Technology Cooling (XTC) – thermal-regulated turbo-charged inner cooler, supplies fan forced cool

air evenly and constantly through tightly packed, bonded ﬁns. Fan speed is continuously variable and

controlled by ampliﬁer’s output load, temperature of heatsink and transformers. Exhaust of internal heatsink is

strategically positioned to cool transformers to maintain maximum performance at all volumes.

3. Bi-Level Inputs with Smart Engage – All MTX ampliﬁers feature RCA type input connections. All MTX

ampliﬁers allow both high level and line level input into the RCA type input connections.

• Low Level Input – All MTX ampliﬁers feature RCA type input connections. Source units with an output

signal level of 100mV–10V may be used. See “Input Sensitivity” for proper voltage level setting.

• High Level Inputs with Smart Engage – All MTX ampliﬁers allow high level inputs through RCA type input

connections using provided high level adapters. Source units with an output signal level of 100mV–10V may

be used. See “Input Sensitivity” for proper voltage level setting.

• Smart-Engage” Auto-turn-on: is an auto turn-on circuit included within the ampliﬁer. A remote turn-on

wire is not necessary when connecting the ampliﬁers high-level input to a high-powered source unit (Car

Stereo). The ampliﬁer will automatically turn on when music is received through this type of connection.

Note: Smart engage is only active on the left input.
