MTD 330 Series User Manual
Page 15
15
Model Series 300 & 330
Ref.
No.
Part No.
Part Description
1.
734-1988
Wheel 8 x 1.75
734-1781
‡
Wheel 8 x 1.8
2.
738-0929
Shoulder Screw
3.
686-0081A
Wheel Bracket Assembly
4.
714-0149B
Cotter Pin
5.
711-0415
Clevis Pin
6.
736-0242
Bell Washer.340 ID x.872 OD
7.
710-0189†
Hex Cap Screw 5/16-18 x 3.0
710-0176
‡
Hex Cap Screw 5/16-18 x 2.75
8.
738-0934
Shoulder Screw
9.
786-0145A
Engine Mounting Plate
10.
750-0470
Spacer.47 OD x.96Lg
11.
686-0189†
Chain Case Assembly
686-0091
‡
Chain Case Assembly
12.
712-0429
Hex Lock Nut 5/16-18
13.
736-0171
Lock Washer 7/16
14.
712-0240
Jam Nut 7/16-20
15.
642-0002
‡
Inner Tine Assembly - RH 12”
642-0003
‡
Inner Tine Assembly - LH 12”
16.
642-0004
‡
Outer Tine Assembly -RH 12”
642-0005
‡
Outer Tine Assembly - LH 12”
17.
710-0502A
Hex Washer Screw 3/8-16 x 1.25
18.
712-3010
Hex Nut 5/16-18
19.
736-0242
Bell Washer.340 ID x.872 OD
20.
710-3180
Hex Cap Screw 5/16-18 x 1.75
21.
750-0273†
Spacer, .51 x .69 x 1.97
22.
04922†
Tine 9.5” RH
23.
04923†
Tine 9.5” LH
24.
711-0702†
Clevis Pin
25.
04918†
Tine Adapter
26.
710-0599†
Self-tapping Screw, 1/4-20 x .5
27.
750-0456†
Spacer, .790 x .347
Ref.
No.
Part No.
Part Description
† Series 300 Only
‡ Series 330 Only
