Marmitek Wireless Audio/Video System GigaVideo45 - Manual (Page 2)

GigaVideo45 ™
A/V EQUIPMENT
A/V RECEIVER
A/V TRANSMITTER REMOTE CONTROL
PC/SAT/
DVD/VIDEO
TV
IR EXTENDER
INFRARED
REMOTE
CONTROL
RECEIVER
(433 MHz)
INFRARED
REMOTE
CONTROL
TRANSMITTER
(433 MHz)
AUDIO/VIDEO
TRANSMITTER
(2.4 GHz)
AUDIO/VIDEO
RECEIVER
(2.4 GHz)
VIDEO IN
AUDIO IN
DC ADAPTER
VIDEO OUT
AUDIO OUT
DC ADAPTER
2 0 0 7 © M A R M I T E K 2 2 7 0 5 / 2 0 0 7 0 1 0 8
Transmitter
Receiver
Range: Up to 100m free field, up to 30m through
walls and ceilings
Power: 230VAC/50Hz, 6VDC 300mA
Transmitter: 2,4G Hz, 4 channels (A, B, C, D)
IR extender: 433MHz
AV input: 3x Cinch (2x Audio, 1x Video)
Video input: 1Vpp (typ) 75 Ω
Audio input: 1Vpp (typ) 600 Ω
Dimensions: 92x85x140mm (with upright antenna)
Power: 230VAC/50Hz, 6VDC 300mA
Receiver: 2,4GHz, 4 channels (A, B, C, D)
AV output: 3x Cinch (2x Audio, 1x Video)
Video Output: 1Vpp (typ) 75 Ω
Audio Output: 1Vpp (typ) 600 Ω
Audio: Stereo
Dimensions: 92x85x140mm (with upright antenna)
Technical data
Set includes
GigaVideo45 ™
Order information
www.marmitek.com
EU version Art.nr. 09567
UK version Art.nr. 09629
Size (L x W x H) 207x113x160mm
GigaVideo45™
Giftbox
Job no. Filename
Colours
GigaVideo45 AZ.ai
13-11-2007 CYAAN MAGENTA YELLOW BLACK
Also available
1x A/V Transmitter 1x A/V Receiver 2.4 GHz extra receiver
To receive the signal of
the sender at more TVs
Art.nr. 09488 S-video to composite video
adapter
To transmit the S-video
signal into a composite
video signal Art.nr. 09388
EasyControl4/6™ and EasyTouch25™
To control your TV and A/V devices with
one remote control
Art.nr. 09660 / Art.nr. 09661 / Art.nr. 09663
2x Power adapter Flat TV Link 4™
To connect 4 A/V devices to
your GigaVideo45™
EU version Art.nr. 09592
UK version Art.nr 09608
2x RCA cable +
scart adapter
1x IR extender cable
with 3 LEDs
1x 3,5 mm jackplug-
RCA adapter
1x User manual
English, Deutsch,
Français, Español,
Italiano, Nederlands.
1x Scart doubler
