Murphy Series A900 - Manual (Page 18)

5-1/2 in.
(140 mm)
3-3/4 in.
(95 mm)
3/16 in.
(5 mm) dia.
4 places
5-5/8 in.
(143 mm)
2-13/16 in.
(71 mm)
3 in.
(76 mm)
3-3/8 in.
(86 mm)
6-3/4 in.
(171 mm)
9-3/8 in.
(238 mm)
6 in.
(152 mm)
4-15/32 in.
(114 mm)
Mounting
Holes
1/8 in.
(3 mm)
diameter
1-1/2 in.
(38 mm)
clearance
5 in. (127 mm) maximum
between A-900 Series module
& relay module when mounting
1-7/8 in. (48 mm)
clearance
1-7/8 in. (48 mm)
clearance
Figure 4-1.2.5: Mounting Dimensions
A900 Series
Module
Relay Module
