Installation
5
Water Connection
1. A cold water supply should be connected to the water
inlet located on the rear right hand side of the unit.
2. A connection elbow and
sealing washer are supplied
with this unit for direct
connection of a ¾” ID hose,
and is recommended for
easy installation and service.
3. Connect to the water supply.
- Max Inlet Pressure 80psi / 550kPa.
4. Turn ‘On’ the water supply to check for water leaks.
NOTE: The Prover / Holding Cabinet can be fitted with
an optional Water Filter Kit (Part No. 234347).
For fitting instructions refer to the Instruction
Sheet supplied with the Water Filter Kit.
Water
Connection
