Manual Climate Control
back-up Camera
Fan control dial
• Rotate the dial
to set desired fan
speed (1-4).
temperature
control dial
• Rotate the dial to
select a warmer
or cooler air
temperature.
mode selector dial
• Rotate the knob to
select airflow mode.
Economically and
efficiently cools the
vehicle while
recirculating cabin
air to reduce
exhaust odors.
Uses outside air to
cool the vehicle.
Air flows from the
instrument panel
vents only.
Dashboard vents
Dashboard and
floor vents
Floor vents
Defroster and
floor vents
Windshield
Defroster
A/C
MAX
A/C
