21
REPLACEMENT PARTS
CONVEYOR/CURTAIN/SWITCH ASSEMBLY
Fig. 6 Part Part Description Qty.
Item No. No.
1 0700354 Curtain Assembly Complete ...................................................... 1
2 0700997 Curtain Support .......................................................................... 1
3 0501625 Spray Curtain ............................................................................. 1
4 0300998 Curtain Clamp ............................................................................ 1
5 0501538 Nut, 8-32 .................................................................................... 5
6 0501408 Screw, 8-32 x 1/4 ....................................................................... 5
7 0301021 Right Hand Tray DF, DF1.......................................................... 1
7 0701128 Right Hand Tray DF2 ................................................................ 1
8 0707434 Left Hand Tray DF, DF1............................................................ 1
8 0701119 Left Hand Tray DF2................................................................... 1
9 0503810 Plexiglass Divider ...................................................................... 1
10 0307266 Ccnveyor Hub............................................................................. 1
11 0506885 Conveyor Moulded..................................................................... 1
12 0307322 Glide Block ................................................................................ 4
13 0501412 Screw, 10-32 x 3/8 ..................................................................... 4
14 0701011 Shut-off Rod Assembly.............................................................. 1
15 0300848 Activator Assembly DF, DF1..................................................... 1
15 0706935 Activator Assembly DF2............................................................ 1
16 0501395 Set Screw, 1/4-20 x 5/16 ........................................................... 1
17 0301012 Nut Plate..................................................................................... 1
18 0501382 Tripswitch, Sealed ...................................................................... 1
19 0503574 Strain Relief ............................................................................... 1
20 0501483 Delrin Washer............................................................................. 2
21 0503723 Screw, 6-32 x 1" ......................................................................... 2
22 0300980 Switch Support Bracket DF, DF1, DF2 (CW rotation) ............. 1
22 0301008 Switch Support Bracket DF2 (CCW rotation) ........................... 1
