S50W
Frequency Response 50 Hz to 16 kHz
Maximum Power Rating 50 Watts
Impedance 8 Ohms
Overall Dimensions 8 5/8” W x 12” H x 3 3/8” D
Specifi cations
Two way; 6 ½” woofer, 1” mylar swivel
tweeter
Mounting Dimensions 7 3/8” W x 10 ¾” H x 2 7/8” D
Grille Metal
Color White
S40W
Frequency Response 60 Hz to 20 kHz
Maximum Power Rating 40 Watts
Impedance 8 Ohms
Overall Dimensions 7 ½” W x 11” H x 3” D
Specifi cations
Two way; 5 ¼” woofer, 1” mylar
swivel tweeter
Mounting Dimensions 6 1/8” W x 9 5/8” H x 2 5/8” D
Grille Metal
Color White
UNPACKING YOUR SPEAKERS
After carefully unpacking your speakers, the carton and the packing
material should be saved for possible use later. If any speaker
appears to be damaged, do not attempt to repair or to connect the
unit to the amplifi er. Repack the speaker and notify your distributor
or M&S Systems for replacement or repair.
SPEAKER LOCATION
Careful consideration must be given to the speaker location to
realize the full frequency range. In-wall speakers should be spaced
6 to 8 feet apart but no closer than 2 feet to any adjacent wall or
ceiling. Typical height from the fl oor would be in the 4 to 6 foot range.
Avoid placing speakers in air return wall cavities or walls containing
plumbing. Do not install speakers in outside walls, stud cavities
containing 120/240V appliances, within 18 inches of dimmers,
security wiring and other control wiring.
2 of 7
