57
REPLACEMENT PARTS
Fig. 33 Part Part Description Qty.
Item No. No.
1 0509042 Tank, booster ................................................................................. 1
2 110562 Thermostat, high limit (fixed, snap) .............................................. 1
3 110563 Compound, heat sink ..................................................................... 1
4 108954 Nut, grip (6-32 with nylon insert) ................................................. 2
5 100210 Plug 1/8 (SST) ............................................................................... 1
6 100154 Nut, plain (5/16-18) ....................................................................... 2
7 106013 Washer, lock (5/16 split) ................................................................ 2
8 104618 Washer, flat (3/8 X 7/8 X 1/16) ..................................................... 2
9 102376 Washer, flat (5/16 X 3/4 X 1/16) ................................................... 2
10 100740 Bolt (5/16-18 X 1 Hex hd) ............................................................ 2
11 106482 Washer, lock (1/4 split) .................................................................. 3
12 100003 Nut, plain (1/4-20 SST) ................................................................. 3
13 111233 Heater, booster, 9 KW (208-240V) 40
° rise (1 & 3 PH) ..............
1
14 108579 Heater, booster, 9 KW (480V) 40
° rise (3PH) ..............................
1
15 111266 Heater, booster, 18 KW (208-240V) 70
° rise (3 PH) ...................
1
16 111267 Heater, booster, 18 KW (480V) 70
° rise (3PH) ............................
1
17 109985 O-ring ............................................................................................ 1
18 112204 Thermostat, booster heat control (includes item 21) ..................... 1
19 112185 Bracket, thermostat ........................................................................ 1
20 107966 Nut, grip (10-32 w/nylon insert) ................................................... 2
21 ——— Screw (6-32 X 1/4) (included with Item 18) ................................. 2
22 107550 Valve, pressure reducing (3/4") ..................................................... 1
— 900772 Kit, thermostat (includes Items 18, 19, 21) ................................... 1
MH-60 ONLY
ELECTRIC BOOSTER ASSEMBLY
