Issue 5: 4 May 2005 A3.5 CD Instructions for use Page 16 of 17
A3.5 CD
Upsampling 24 Bit SPECIFICATIONS
Compact Disc Player
DAC architecture
24 bit Delta-Sigma (Bitstream)
Dual differential
8x oversampling
Disc
mechanism Philips
Upsampling
96kHz
Frequency response
10Hz to 20kHz +0 / -0.2dB
Signal / noise ratio
> 115dB “A” weighted
Total harmonic distortion
< 0.006% 10Hz to 20kHz
Total correlated jitter
< 170 pS
Channel separation
> 100dB 20Hz to 20kHz
Linearity
< 0.2dB down to -90dB
Audio output at digital 0dB level
2.14VRMS at 1kHz nominal
Analog output
1 pair RCA connectors
Analog output impedance
50 Ohms
Digital outputs
1 optical (Toslink),
1 S/PDIF (RCA connector)
Power requirements
100 / 115 / 230V AC 50 / 60Hz (factory preset)
15 Watts
Dimensions
(approximate) 440mm, 17.3 inches wide
100mm, 3.9 inches high including feet
395mm, 15.6 inches deep including terminals
Weight
10.8 kg, 22.8 lbs unit only, un-boxed
15.5 kg, 34.2 lbs in shipping carton
Standard accessories
IEC mains lead (10 Amp type),
Remote control handset (A3.5 type, universal),
2 batteries size LR03 or AAA, manganese alkaline type
Musical Fidelity reserves the right to make improvements which
may result in specification or feature changes without notice.
